• Model NO.：Outdoor P8
• Pixel Density：15625DOT,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL, SGS ISO
• Brightness：More Than 8000CD,Sqm
• waterproof：IP65
• Price and Advantage：Factory Price and LED Dotmatrix Display Manufactur
• Warranty Time：3-5years
• Programmable Card：Outdoor Video LED Display Panel
• Colors：16777216
• Support Input Signal：HDTV CATV NTSC PAL S-Video VGA VCD DVD
• Interface：Network,Erial Port,50 Chip,Parallel RS 232,Solar P
• Delivery Detail：3-5working Days
• Diode Model：Silan,Nichia,CREE,Epistar,Opto
• Transport Package：Anti-Shakging Wooden ;Air Flight Case;Carton Packa
• Specification：CE, RoHS, SGS, etc.
• Trademark：FOXGOLDEN
• Origin：Shenzhen
• HS Code：8528591090
• Production Capacity：4000 Square Meters , Month

P8 Outdoor Lamp Display SpecificationTechnical SpecificationPixel Pitch8mmDensity of Pixel15625dots/m 2Pixel configuration1R1G1BSize of Single Board1024mm1024mmColors16777216Best Viewing Distance≥8mHorizontal Viewing Angle140°Maximum Power Consumption≤1100W/m 2Brightness7500cd/m 2Gray Scale14 bits per colorColor Temperature6500kControl Methodto be synchronized with computer monitorDriving method1/2 scanningFrame Frequency60HzRefresh frequency3000HzWorking VoltageAC220V/110V±10%IP gradeIP65Working temperature20degree centigrade +70 degree centigradeComputer operation systemWin 98/  Win XP/  Win 2000Brightness adjustment256 grade manual, 8 grade automaticVideo signalRF, S-Video, RGB, RGBHV, YUV, YC.ectSoftwareLED play softwareMTBFMore than 10000 hoursLife Span100,000 hours







Foxgolden Group Ltd
Address:  No.57,Shuitian Fourth Industrial Park,Shiyan Town,Baoan District,Shenzhen City,China

Foxgolden had been engaged in designing and manufacturing LED display for more than 11 years. Our products have certificates like CE/FCC/RoHS/NQA /SGS/ISO.
The best quality products and excellent service will be provided to you by our professional team.
