Waterproof P20 LED Screen Outdoor LED Curtain
Panhong Chemical Co., Limited.- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：20mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：600W , m²
Base Info
- Model NO.：P20
- Pixel Density：2500
- Scanning Mode：1,8 Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, RoHS
- Product：P20 Full Color
- Size of Modual：320*160mm
- Pitch Pixel：20mm
- Cabinet Size：960*96mm
- waterproof：IP67front, IP65 Back
- Power Consumption：About 500W,Sqm
- Brightness：8000CD,M2
- Best Viewing Distance：20-300m
- Life Span：More Than 100, 000hours
- Transport Package：Anti-Shaking Wooden;Air Flight Case;Carton Case
- Specification：CE, SGS, RoHS, etc.
- Trademark：FOXGOLDEN
- Origin：Shenzhen
- HS Code：8531200000
- Production Capacity：4000sqm,Month
Description
Technical parameterUnit module Module size 320*160mm Pixel pitch 20mm Pixel density 2500dots/m2 Pixel configuration 2R1G1B Led specification Φ 5ellipse Pixel resolution W: 16dots*H: 8dots Cabinet Dimension 960mm*960mm*170mm Quantities of module 18pcs Power supply 4pcs Thermal discharge Fan*2pcs Total weight 55kg Best viewing angle 16-300m Temperature Storage: -35° C~+85° C Working: -35° C~+85° C Thickness 17cm can adjustable Remarks: cabinet size can changed, upon project need. Power Working voltage AC220V/110V± 10% Average power consumption 250-500W Max. Power consumption ≤ 560W/sqm Current ≤ 20mA(single LED) Control system CPU Pentium4 or above Operating system WIN98/2000/NT/XP Control method Synchronization Main technical parameter Driving device Static scanning Drive type Constant Current driver IC Refresh frequency ≥ 400Hz Grey scale/colors 256 levels of each color(R/G/B)/16.7M color Brightness of white balance More than 8000cd/sqm Brightness adjustment 256 levels of each color(R/G/B)by software Operating ambient humidity 10%--95% Video signal PAL/NTSC Control system DVI display card+full color controller card MTBF ≥ 10, 000hours Life span ≥ 100, 000hours Flatness Tolerance of interpixel ≤ 0.3mm Tolerance of modules clearance≤ 0.6mm Power switch Automatic switch Display mode 1024*768 Communication distance Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m.
Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM Software LED media player
Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM
