• Model NO.：P5-Indoor-SMD
• System Operating Platform：WIN XP
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP43
• Certification：CE, RoHS, CCC
• Module：P5
• Size：160*160mm
• Pixel：5mm
• Density：40000dots,M2
• 40000dots/M2：3528 Dotmatrix 3 in 1
• Total Weight：45kg
• Best Viewing Angle：2-50m
• Transport Package：Anti-Shaking Wooden Case&Flight Case &Carton
• Specification：P5
• Trademark：FOXGOLDEN
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：4000sqm,Month

Technical parameterUnit moduleModule size160*160mmPixel pitch5mmPixel density40000dots/m2Pixel configuration1R1G1BLed specification3528 dotmatrix 3 in 1Pixel resolutionW: 32dots*H: 32dotsCabinetDimension960mm*960mm*110mmQuantities of module36pcsPower supply6pcsThermal dischargeFan*2pcsTotal weight45kgBest viewing angle2-50mTemperatureStorage: -35degree~+85degreeWorking: -20degree~+80degreeThickness11cm can adjustableRemarks: cabinet size can changed, upon project need.PowerWorking voltageAC220V/110V± 10%Average power consumption350WMax. Power consumption≤ 900W/sqmCurrent≤ 20mA(single LED)Control systemCPUPentium4 or aboveOperating systemWIN98/2000/NT/XPControl methodSynchronizationMain technical parameterDriving device1/16scanningDrive typeConstant Current driver ICRefresh frequency≥ 300HzGrey scale/colors256 levels of each color(R/G/B)/16.7M colorBrightness of white balanceMore than 2200cd/sqmBrightness adjustment256 levels of each color(R/G/B)by softwareOperating ambient humidity10%--95%Video signalPAL/NTSCControl systemDVI display card+full color controller cardMTBF≥ 10, 000hoursLife span≥ 100, 000hoursFlatnessTolerance of interpixel ≤ 0.3mmTolerance of modules clearance≤ 0.6mmPower switchAutomatic switchDisplay mode1024*768Communication distanceUnshielded twisted pair net line transmission distance 100m, max transmission distance 200m.
Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KMSoftwareLED media player
