Hot Sell P4.81 Full Color Outdoor LED Screens for Concert Stage
Guangzhou Zhonghao Packaging Products Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：4.81mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：600W , m²
Base Info
- Model NO.：3.91mm, 4.81mm, 6.25mm
- Pixel Density：43264pixels,Sqm
- Scanning Mode：1,13
- Display Type：LED Video Display
- Application：Stage Performance
- Certification：CE, RoHS
- Delivery Time：20 Days
- Warranty：2 Years
- LED Type：SMD2727
- LED Brand：Epistar
- Cabinet Size：500mmx500mm
- Module Size：250mmx250mm
- Lifetime：100000hours
- Transport Package：Flight Case, Plywood Case, Carton.
- Specification：CE, ROHS, ISO9001
- Trademark：BST
- Origin：Shenzhen, China
- HS Code：8528591090
- Production Capacity：5000sqm,Month
Description
| LED Display Series | BST-ORD-3 | BST-ORD-4 | BST-OR-6 |
| Pixel Pitch(mm) | 3.91 | 4.81 | 6.25 |
| Pixel Density(dots/m2) | 65536 | 43264 | 25600 |
| Avr Power Consumption (W/M2) | ≤500 | ≤500 | ≤500 |
| Brightness Max(cd/m2) | ≥6500 | ≥6500 | ≥6500 |
| Color Temperature(after calibration)K | 6500 | 6500 | 6500 |
| Cabinet Material | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum |
| Weight(kg/Panel) | 10 | 10 | 10 |
| Working Humidity | 10%-95% | 10%-95% | 10%-95% |
| Driving Method | 1/8 | 1/13 | 1/10 |
| LED Type | SMD2727 | SMD2727 | SMD3535 |
| Horizontal/Vertical Viewing Angle(º) | H140º/V140º | H140º/V140º | H140º/V140º |
| Recommended Viewing Distance(m) | 1--100 | 1-100 | 1--100 |
| Power Supply | Single power | Single power | Single power |
| Refresh Rate(Hz) | ≥1920 | ≥1920 | ≥1920 |
| Weight(kg/m2) | 40 | 40 | 40 |
| Grey Scale(bit) | R'G'B 16bit | R'G'B 16bit | R'G'B 16bit |
| Frame Rate(Hz) | 50/60 | 50/60 | 50/60 |
| Life Time(H) | ≥100000 | ≥100000 | ≥100000 |
| Protection | Outdoor | Outdoor | Outdoor |
| Cabinet Size(W*H)(mm) | 500x500 | 500X500 | 500X500 |
| LED Chip | Epistar | Epistar | Epistar |
| Contrast | 2000:1 | 2000:1 | 2000:1 |
| Protection | IP65 | IP65 | IP65 |
| Max Power Consumption(W/M2) | 900 | 900 | 900 |
| Working Temperature | -20C°/40C° | -20C°/40C° | -20C°/40C° |
| Module Size(W*H)(mm) | 250X250 | 250X250 | 250X250 |
| Driving Chip | MBI5124 | MBI5124 | MBI5124 |
| Control Input | DVI/HDMI/HDSDI | DVI/HDMI/HDSDI | DVI/HDMI/HDSDI |
| Max Hanging(Vertical) | ≥200kg | ≥200kg | ≥200kg |
