• Model NO.：P6, P8, P10, P16
• Pixel Density：15625 Pixels,Sq.M
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC
• Warranty：2 Years
• LED Type：SMD3535
• LED Brand：Epistar
• Refresh Rate：>1500Hz
• Brightness：>6500nits
• OEM：Yes
• Delivery Time：20 Days
• Transport Package：Flight Case, Plywood Case, Carton.
• Specification：CE, ROHS, ISO9001
• Trademark：BST
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：5000sqm,Month

Basic Info.

Model NO. P6, P8, P10, P16 Pixel Density 15625 Pixels/Sq.M Scanning Mode 1/4 Scan Display Type LED Video Display Application Advertising Certification CE, RoHS, CCC Warranty 2 Years LED Type SMD3535 LED Brand Epistar Refresh Rate >1500Hz Brightness >6500nits OEM Yes Delivery Time 20 Days Transport Package Flight Case, Plywood Case, Carton. Specification CE, ROHS, ISO9001 Trademark BST Origin Shenzhen, China HS Code 8528591090 Production Capacity 5000sqm/Month

Product Description

Hot sell P8 SMD3535 Outdoor Full Color led display screen for commercial advertising



Key Benefits

1. Broad viewing angle;
2. Frame-free installation;
3. Front and rear side maintenance.
4. High brightness, visible even with direct sunshine;
5. High waterproof and dustproof, IP65 both front and rear side
6. Having good lightening accordance and no mosaic;
7. Having large viewing angle: Getting vivid effect within any position of the viewing range;
8. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.

LED DISPLAY, LED STADIUM SCREEN, LED OUTDOOR SCREEN, OUTDOOR BILLBOARD

Model	PH8
Pixel  Pitch	8mm
Unit  Size	1024mm x 768mm
LED  Type	1R1G1B
Pixel / Unit	128x96
Unit  Weight	52kg(steel) or 36kg(Aluminum)
Viewing  Angle	H140°   V70°
Application	Storage-40~60° C,     Working-20~50° C
Protection  Level	IP65
Power  Consumption	620W/panel  Max
	250W/Panel  Ave.
Driving	1/4
Frame  Refresh	≥60Hz
Data  Refresh  Rate	1200~4000Hz
Processing	16bit
Max    Brightness	5,500-6500nits
Power  Supply	AC90-240V,   50~60Hz
MTBF	≥1000  Hours
Life  Span	≥50000  Hours
Pixel  Failure	< 0.0003
