Slim Full Color Stage LED Display Screen (P6 Indoor)
Xuzhou Whuchan Co., Ltd- Tube Chip Color：Full Color
- Display Function：Video Display
- Pixel Pitch：6mm
- Pixel Configuration：1R,1G,1B
- Pixel Density：27777dots,Sq.M
- Scanning Mode：1,8 Scan
Base Info
- Model NO.：P6-768
- System Operating Platform：Win XP,Win 2000,Win7,8
- Display Type：LED Video Display
- Application：Stage Performance, Advertising, Shopping Guide
- IP Rating：IP43
- Certification：CE, RoHS, CCC, FCC
- Cabinet Size：768X768mm
- Cabinet Material：Aluminum Alloy
- Module Size：192X192mm
- LED Type：SMD3528
- Transport Package：Flight Case or Wooden Case
- Specification：CE, FCC. ROHS, 3C
- Trademark：PRT
- Origin：Shenzhen
- HS Code：8528591090
- Production Capacity：2000sq. M,Month
Description
P6 SMD3528 Indoor full Color LED Screen SpecificationPixel pitch 6mm Pixel Configuration 1R1G1B LED component SMD3528 Size of module 192mm X 192mm Resolution of module 32 x32 Size of cabinet 768mm x768mm x 80mm Resolution of cabinet 128x128 Material of Cabinet Aluminum Profile Weight of Cabinet 10KGS Brightness >1500cd/sq.m Density 27777dots/sq.m Best viewing angle 140 /140 Pixel Configuration 1R1G1B Best viewing distance 5-60M Maximum power consumption 600W/sq.m Average power consumption 360W/sq.m Driving method 1/8 scan Control method Synchronization Gray scale 65536 Colors 256*256*256 Color temperature 3200-9300k Uniformity 97% Working voltage AC220V/110V±10% Working temperature -20ºC~+50ºC±10% Working humidity 10% ~ 90% MTBF 10,000 hours Frame frequence 50/60Hz Refresh frequence >1920Hz IP grade IP31 Life Span 100,000 hours Data transafer method RJ45 Pratical standard CCC TUV-CE ETL etc. Effectivce Communication
Distance(without relay) Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
