Outdoor P8 Full Color LED Sign Board (Rental design 640X640mm)

Xuzhou Whuchan Co., Ltd
  • Tube Chip Color：Full Color
  • IP Rating：IP65
  • Pixel Pitch：8mm
  • Pixel Configuration：1R, 1G, 1B
  • Display Function：Video Display
  • Average Power Consumption：350W , m²

Base Info

  • Model NO.：P8
  • Pixel Density：15625dots Per Sqm
  • Scanning Mode：1,5scan
  • Display Type：LED Video Display
  • Application：Stage Performance, Advertising
  • Certification：CE, RoHS, CCC, FCC
  • LED Type：SMD3535
  • Module Size：320X160mm
  • Module Resolution：40X20dots
  • Cabinet Size：640X640mm
  • Transport Package：Flight Case
  • Specification：CE, FCC, Rohs
  • Trademark：PRT
  • Origin：Shenzhen China
  • HS Code：8528591090
  • Production Capacity：3000sqm,Month

Description

P8 Outdoor full Color LED Screen SpecificationPixel pitch8mmPixel Configuration1R1G1BLED componentSMD3535 blackSize of module320mm x 160mmResolution of module40x20Size of cabinet640mm x 640mm x 65mmResolution of cabinet96x96Material of CabinetDie-casting AluminumWeight of Cabinet<13KGSBrightness>6000cd/sq.mDensity15625dots/sq.mBest viewing angle140 /140Best viewing distance6-100MMaximum power consumption<1000W/sq.mAverage power consumption<300W/sq.mDriving method1/5 scanControl methodSynchronizationGray scale65536Colors256 x 256 x 256Color temperature3200-9300kUniformity97%Working voltageAC220V/110V±10%Working temperature-20ºC~+50ºC±10%Working humidity10% ~ 90%MTBF10,000 hoursFrame frequence50/60HzRefresh frequence>1800HzIP gradeIP65Life Span100,000 hoursData transafer methodRJ45Pratical standardCCC  TUV-CE  ETL etc.Effectivce Communication
Distance(without relay)Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KMAccepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.Systems operating platformWINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
