P5 Full Color LED Display Panel for Permanent Fixed/Rental
Xuzhou Whuchan Co., Ltd- Tube Chip Color：Full Color
- Display Function：Video Display
- Pixel Pitch：5mm
- Pixel Configuration：1R,1G,1B
- Pixel Density：40,000 dots , m²
- Scanning Mode：1,16 Scan
Base Info
- Model NO.：P5
- System Operating Platform：Win XP,Win 2000,Win7,8
- Display Type：LED Video Display
- Application：Stage Performance, Advertising, Shopping Guide
- IP Rating：IP43
- Certification：CE, RoHS, CCC, FCC
- Cabinet Size：640X640mm
- LED Encapsulation：SMD3528
- Module Size：160X160mm
- Module Resolution：32X32dots
- Transport Package：Flight Case or Wooden Case
- Specification：CE, FCC. ROHS, 3C
- Trademark：PRT
- Origin：Shenzhen
- HS Code：8528591090
- Production Capacity：3000sq. M,Month
Description
P5 Indoor full Color LED Screen SpecificationPixel pitch 5mm Pixel Configuration 1R1G1B LED component SMD3528 Size of module 160mm x 160mm Resolution of module 32x32 Size of cabinet 640mm x 640mm x 150mm Resolution of cabinet 160 x160 Material of Cabinet Iron/Aluminum Weight of Cabinet 15KGS Brightness >1500cd/sq.m Density 40000dots/sq.m Best viewing angle 140 /140 Best viewing distance 4-35M Maximum power consumption <800W/sq.m Average power consumption <400W/sq.m Driving method 1/16 scan Control method Synchronization Gray scale 65536 Colors 256 x 256 x 256 Color temperature 3200-9300k Uniformity 97% Working voltage AC220V/110V±10% Working temperature -20ºC~+50ºC±10% Working humidity 10% ~ 90% MTBF 10,000 hours Frame frequence 50/60Hz Refresh frequence >2000Hz IP grade IP65 Life Span 100,000 hours Data transafer method RJ45 Pratical standard CCC TUV-CE ETL etc. Effectivce Communication
Distance(without relay) Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
Distance(without relay)
Single-mode optic fiber: 10KM
