High Refresh Rate P16 RGB Full Color Outdoor Giant Advertising LED Screen
Guangzhou Zhonghao Packaging Products Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：16mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：600W , m²
Base Info
- Model NO.：BST-P16-OF
- Pixel Density：3906 Pixels,Sq.M
- Scanning Mode：Static Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, RoHS
- Warranty：2 Years
- Delivery Time：20 Days
- Module Size：256mmx128mm
- Cabinet Size：1024mmx768mm
- OEM：Yes
- Refresh Rate：>1500Hz
- Transport Package：Flight Case, Plywood Case, Carton.
- Specification：CE, ROHS, ISO9001
- Trademark：BST
- Origin：Shenzhen, China
- HS Code：8528591090
- Production Capacity：5000sqm,Month
Description
Basic Info.
Model NO. BST-P16-OF Pixel Density 3906 Pixels/Sq.M Scanning Mode Static Scan Display Type LED Video Display Application Advertising Certification CE, RoHS Warranty 2 Years Delivery Time 20 Days Module Size 256mmx128mm Cabinet Size 1024mmx768mm OEM Yes Refresh Rate >1500Hz Transport Package Flight Case, Plywood Case, Carton. Specification CE, ROHS, ISO9001 Trademark BST Origin Shenzhen, China HS Code 8528591090 Production Capacity 5000sqm/MonthProduct Description
High refresh rate P16 RGB Full Color Outdoor Giant Advertising LED Screen
Key Benefits1. Broad viewing angle;
2. Frame-free installation;
3. Front and rear side maintenance.
4. High brightness, visible even with direct sunshine;
5. High waterproof and dustproof, IP65 both front and rear side
6. Having good lightening accordance and no mosaic;
7. Having large viewing angle: Getting vivid effect within any position of the viewing range;
8. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
LED DISPLAY, LED STADIUM SCREEN, LED OUTDOOR SCREEN, OUTDOOR BILLBOARD
| Model | PH16 |
| Pixel Pitch | 16mm |
| Unit Size | 1024mm x 1024mm |
| LED Type | 1R1G1B |
| Pixel / Unit | 64x64 |
| Unit Weight | 68kg(steel) or 48kg(Aluminum) |
| Viewing Angle | H140° V70° |
| Application | Storage-40~60° C, Working-20~50° C |
| Protection Level | IP65 |
| Power Consumption | 800W/panel Max |
| 420W/Panel Ave. | |
| Driving | Static |
| Frame Refresh | ≥60Hz |
| Data Refresh Rate | 1200~4000Hz |
| Processing | 16bit |
| Max Brightness | 5500-6500nits |
| Power Supply | AC90-240V, 50~60Hz |
| MTBF | ≥1000 Hours |
| Life Span | ≥50000 Hours |
| Pixel Failure | < 0.0003 |
