Basic Info.

Model NO. Mini Machine Weight 1.8t Certification CE, ISO9001:2008 Machine Model Mini Type Transport Package Wrapping Film Specification CE Trademark Changyin Origin China HS Code 84773090 Production Capacity 1000sets/Year

Product Description

Performance and Characteristics:
The machinge body is channel steel frame traction frequency friction, with single rolling friction, lift up and down which is suitable for blowing high-low pressure polyethylene industral fiml and agricultural film.
Main Teachnical Variables:
We can make the machine as your request.

Model	SJ- A 45	SJ- A50
Suitable Material	LDPE,HDPE,LLDPE	LDPE,HDPE,LLDPE
Screw   Diameter	45MM	50MM
F ilm  Width (mm)	100- 5 00	3 00- 6 00
Film  Thickness (mm) (HD)	0.00 9 -0.0 5	0.00 9 -0.0 5
Film  Thickness (mm) (LD)	0.02-0.15	0.02-0.15
Max  Extrusion O utput(kg/h) (HD)	40	45
Max  Extrusion O utput(kg/h) (LD)	4550	50
Screw  L/D  Length	28:130:1	28:130:1
M ain  M otor(kw)	7.5	11
Take-up Motor (kw)	0.75	1.1
Outline  Dimension (L × W × H)(m)	5 . 0×2 . 0×4 .1	5 . 0×2 .2 ×4 .5
