P8 SMD3535 Full Color Outdoor LED Display with 640 X 640 mm Die-Casting Cabinet
Xuzhou Whuchan Co., Ltd- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：8mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：350W , m²
Base Info
- Model NO.：P8-outdoor
- Pixel Density：15625dots,Sq.M
- Scanning Mode：1,5scan
- Display Type：LED Video Display
- Application：Advertising,Stage Performance,Rental
- Certification：CE, RoHS, CCC
- LED Encapsulation：SMD3535
- Module Size：320X320mm
- Module Resolution：80X80dots
- Cabinet Size：640X640mm
- Transport Package：Wooden Case or as Required
- Specification：CE, FCC. ROHS, 3C
- Trademark：PRT
- Origin：Shenzhen China
- HS Code：8528591090
- Production Capacity：3000sq. M,Month
Description
Outdoor Full Color LED Display Main ParametersVisual Characteristics Unit Value Pixel Pitch mm 8.0 Pixel Density Dots/sq.m 15625 Pixel Configuration SMD3535 Cabinet Resolution dots 80×80 Refresh Rate Hz ≥1800 View Angle(H/V) ° 150/120 Brightness nits ≥5500 Gray Scale Bit 16 IP Rating 65 Power Consumption(Max/Avg) W/sq.m 1200/400 Input Voltage(AC) V 110~240 Modular Characteristics Cabinet Size(W×H×D) mm 640x640 Cabinet Material Iron Cabinet Weight Kg 35 Module Size(W×H) mm 320×160 Environment Operation Temperature ºC -20~+40 Operating Humidity 10%~90% Driving Mode 1/4 Scan Control Distance Cat 5E <100m,Single mode fiber<10Km
