Waterproof P6 Full Color Outdoor LED Display Module
Panhong Chemical Co., Limited.- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：6mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：600W , m²
Base Info
- Model NO.：P6
- Pixel Density：27777
- Scanning Mode：1,4 Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, RoHS, CCC
- Brightness：7500-8000CD,Sqm
- Life Span：10, 000hours
- IP Grade：IP65
- Warranty Year：3year
- Viewing Distance：6-300m
- Product：Waterproof P6 Full Color Outdoor LED Display Modu
- Module Size：192X192mm
- Viewing Angle：120degree
- Density：27777dots,M2
- Power Consumption：Average:650W Max:1000W
- Transport Package：1. Anti-Shaking Wooden Package. 2. Air Flight Case
- Specification：CE&ROHS&UL&FCC&SGS&3C
- Trademark：FOXGOLDEN
- Origin：Shenzhen, China
- HS Code：8528591090
- Production Capacity：10, 000PCS,Month
Description
Technical parameterUnit module Module size 192*192mm Pixel pitch 6mm Pixel density 27777dots/m2 Pixel configuration 1R1G1B Led specification Φ 5ellipse Pixel resolution W: 16dots*H: 8dots Cabinet Dimension 1024mm*768mm*110mm Quantities of module 24pcs Power supply 5pcs Thermal discharge Fan*2pcs Total weight 55kg Best viewing angle 12-300m Temperature Storage: -35degree~+85degree Working: -35degree~+85degree Thickness 11cm can adjustable Remarks: cabinet size can changed, upon project need. Power Working voltage AC220V/110V± 10% Average power consumption 500W Max. Power consumption ≤ 1000W/sqm Current ≤ 20mA(single LED) Control system CPU Pentium4 or above Operating system WIN98/2000/NT/XP Control method Synchronization Main technical parameter Driving device Static scanning, also virtual Drive type Constant Current driver IC Refresh frequency ≥ 400Hz Grey scale/colors 256 levels of each color(R/G/B)/16.7M color Brightness of white balance More than 9, 000cd/sqm Brightness adjustment 256 levels of each color(R/G/B)by software Operating ambient humidity 10%--95% Video signal PAL/NTSC Control system DVI display card+full color controller card MTBF ≥ 10, 000hours Life span ≥ 100, 000hours Flatness Tolerance of interpixel ≤ 0.3mm Tolerance of modules clearance≤ 0.6mm Power switch Automatic switch Display mode 1024*768 Communication distance Network calbe: 100m, Multi-model: 500m, Single-model fiber: 20km Software LED media player
