• Pixel Density：10000 dot , m²
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC, ISO9001
• Product Name：Outdoor LED Display P10-4s(SMD)
• Driver IC：Mbi5124
• Bightness CD/Sqm：6000CD,M2
• Grey Scale：65536 Degree
• Life Time：More 100, 000 Hours (80%)
• Mtbf：More 50, 000 Hours
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Color Temperature：6500-9500K
• Warranty：3 Years
• Transport Package：The Factory Packaging
• Specification：320*160mm
• Trademark：hongking
• Origin：China
• HS Code：8528591090
• Production Capacity：5000 Sqm,Year

Technical  SpecificationsNOProduct nameoutdoor P10  led display1Pixel Pitch(mm)10mm2Pixel configuration1R1G1B3Pixel density10000dots/m24Brightness 6000cd/m25Module size(W*H)320mm×160mm6Module Resolution (W*H)32dots x 16dots7Module weight450g8Cabinet size (W*H)960mm×960mm9Drive ICMBI512410Drive mode1/4scan11Viewing Angle(V/H)140ºC12Grey Scale65536 degree13Life time>100,000 Hours (50%)14MTBF>50,000 Hours15Operating VoltageAC110V/220V±10%17Screen Power ConsumptionMax: 680w/m2; Average:220w/m218Input Power Frequency50/60Hz19Operating temperature -30--60ºC20Humidity10%-95%21Refresh Rate≥1200HZ22Control MethodSynchronized with computer monitor23Color Temperature6500K-9500K24LED control systemLINSN,Nova-star,Colorlight is selectable25Control Distance100 m (no repeating); Optical fiber transmission: 500m- 15km26Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI27Systems Operating PlatformWindows Xp / Windows 7 / windows 8 /8.1 / windows 1



Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen



Product Introduction;
1. The total amount of heat reduced
Using energy-saving (low constant current from the control point), high efficiency constant current chip;
Using high brightness and high efficiency of LED lamps;

2. The automated process
All using SMD process, fully automated machine operation, reducing human error and damage and improves reliability.

3. low failure rate
Using sophisticated type of material, in terms of testing: instrument light intensity distribution, it is a direct measurement of the LED lamp light intensity, viewing angle, wavelength, and other optical properties; aging test LED lamps attenuation; an IC testing stand, strict control the quality of the IC. High-temperature aging at the end of the production process and cabinet vibration test, good control of Weld and other issues.

4.fast locks and assembling pins, flatness and seamless are greatly increased, less than 0.01mm , easy to install and dismantle

5. Seamless connection, less than 0.1mm  between 2 cabinet.

6.Most of our product use material as follow:
    MBI5124IC  Driver IC
    E-engcy power supply
     Newlight pcb 1.6mm ,mask and base
     King light and  Anplight  pixel encapsulation
      All our product have three years warranty.
   thank you for your time. Please contact me to know  more.
