P4.81 Full Color Outdoor Rental LED Billboard with 500X500mm Panels
Xuzhou Whuchan Co., Ltd- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：4.81mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：300W , m²
Base Info
- Model NO.：P4.81
- Pixel Density：43264dots,Sq.M
- Scanning Mode：1,13 Scan
- Display Type：LED Video Display
- Application：Stage Performance, Advertising,Rental
- Certification：CE, RoHS, ETL
- Type of LEDs：SMD2727
- Panel Size：500X500mm
- Panel Resolution：104X104 Dots
- Module Size：250X250mm
- Transport Package：Flight Case
- Specification：CE, ROHS, FCC, ETL
- Trademark：PRT
- Origin：Shenzhen China
- HS Code：8528591090
- Production Capacity：3000sq. M,Month
Description
P4.81 Outdoor full Color LED Screen SpecificationPixel pitch 4.81mm Pixel Configuration 1R1G1B LED component SMD2727 Size of module 250mm x 250mm Resolution of module 52x52 Size of cabinet 500mm x 500mm x 75mm Resolution of cabinet 104x104 Material of Cabinet Die-casting Aluminum Weight of Cabinet 8KGS Brightness >6000cd/sq.m Density 43264dots/sq.m Best viewing angle 140 /140 Pixel Configuration 1R1G1B Best viewing distance 3-60M Maximum power consumption 800W/sq.m Average power consumption 300W/sq.m Driving method 1/13 scan Control method Synchronization Gray scale 65536 Colors 256*256*256 Color temperature 3200-9300k Uniformity 97% Working voltage AC220V/110V±10% Working temperature -20ºC~+50ºC±10% Working humidity 10% ~ 90% MTBF 10,000 hours Frame frequence 50/60Hz Refresh frequence >2000Hz IP grade IP65 Life Span 100,000 hours Data transafer method RJ45 Pratical standard CCC TUV-CE ETL etc. Effectivce Communication
Distance(without relay) Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
