• Model NO.：bdssl-008
• Application：Highway, Square, Garden
• IP Rating：IP65
• Certification：CE, RoHS, CCC, ISO, FCC
• Voltage：12V24V
• Height of Pole：4m-12m
• Battery：Gel Battery
• Controler：10A15A20A
• Solar Panel：Polycrystal Monocrystal
• Cable：2.5mm2
• Allocation Design：According to Clients Requirement
• LED Chips：Bridgelux CREE
• Transport Package：Bulk Package
• Specification：CE GSG FCC CE ROHS
• Trademark：LUYOU
• Origin：Yangzhou China
• HS Code：940540900
• Production Capacity：2000sets Per Month

ParametersSolar ModulePmax(W)30-400W Vmp (V)35.0V Imp (A)2.86ALight FixtureMaterialAluminum die casting & Toughened glass Operating Temperature-40°C~75°C Protection LevelIP65LED Light SourceLED ChipBRIDGELUX / Cree (Top brand in U.S.A.) Color Temperature3800-6500K(white) Luminous flux5300 LM Operating temperature-40°C~75°C Current SourceDC 12V/24V Power15W/18W/21W/24W/30W/36W/42W/48W/54W/60WLighting PoleHeight3m/ 4m/ 5m/ 6m/ 7m/ 8m/ 9m/ 10m/ 11m/ 12 m MaterialBAOSTEEL GROUP Q235/345/GR60 Surface TreatmentHot-dip galvanizing, Static spray, Sizeφ60-φ200,δ3-5m, vary according to models Flange Plate300*300*16, vary according to modelsBatteryCapacity200AH (100AH*2pcs)  TypeGel/AGM Battery Dimension546*1203*30 Weight28KgControllerRated voltage and current12V/10A or 24V/10A waterproof  Weight0.165Kg Two times rainy day backup
&Protective FunctionTwo times of rainy day backup.
Good protection: overcharging, discharging, voltage surge, reverse polarity, etc.AccessoriesCable2.5 mm2, 15m Battery Box200AH ABS battery box or metal box with hot-dip galvanizing spray treatment Foundation KitDismountable foundation kit, saving in shippingAFTER SALES

*  BAODE will offer technical guidance and repair service for the whole life time of her products.
*  BAODE promises to respond with customer's questions within 24 working-hours.

Payment terms: 30% in advance and 70% before shipment.
Lead time: 2~3 weeks upon receipt of payment for 50 poles.
Shipping: Generally, solar lights are shipped by sea. Battery and pole are not available to ship by air.
Package: Individual package for each component of solar light. Wooden box for LED lamp and solar panel for LCL goods. 80 poles load a 40 HP container for 8M solar street lights and 60-3.5m solar garden lights in a 20 container.


 Solar Street Light Details



A GRADE high efficient solar panel

Mono: 18% convert efficiency

Poly:  17% convert efficiency

5 years warranty for solar panels



USA BRAND LED and Aluminum Section Bar Light Fixture

LED: BRIDGELUX/CREE

Long life time: 1W LED with 1 heat sink, fast heat dissipation makes it 100,000 hours long life time



STRONGER POLE with 20 years life time

Larger diameter: our pole is 10% larger in diameters

Thicker wall: we offer 0.25mm thicker pole than that of the market. For example, we offer 3mm thickness for 6m pole, while other, 2.5-2.75mm

Bigger foundation kits: for example, we offer M18-20*1000mm bolts for 6m light, while others, M16-18*800mm

Thicker zinc galvanization and painting: we offer 100 μm zinc and coating than the standard 80 μm



TWO TIMES rainy day backup waterproof controller

Rainy day backup: 2 times more rainy day backup, savings in battery

Combined LED driver and controller as one, easy to maintain

IP67: ideal for high humidity and dust areas

Energy saving mode: THREE periods of power adjustment available

All metal shell: high strength and fast heat dissipation, giving long life time



UL LISTED GEL battery

Long service life (1600 cycles @ 30% DOD)

Better Weather-ability (-20 ºC ~ 50 ºC)

Fully sealed construction













We proud of our product
