• Model NO.：XR-16
• X-ray Tube Focal Size：0.8mm
• Transport Package：Aluminum Box
• Specification：135*150*175mm
• Trademark：xrdent
• Origin：China
• HS Code：90184990
• Production Capacity：5000 Pieces,Year

Basic Info.

Model NO. XR-16 X-ray Tube Focal Size 0.8mm Transport Package Aluminum Box Specification 135*150*175mm Trademark xrdent Origin China HS Code 90184990 Production Capacity 5000 Pieces/Year

Product Description

Portable Dental X-ray Machine For Dental ClinicsTechnical Data

Tube voltage	60kV (Fixed)
Tube current	2mA (Fixed)
High voltage generator circuit	High frequency Inverter method
X-ray control method	Controlled by the micro processor
Time setting range	0.01~1.60 second (0.01 sec step)
X-ray tube Type	Stationary anode X-ray tube
X-ray tube model	D-081BS(Toshiba)
Total filtration	1.6mm Al (Inherent filtration: 0.8mmAl, Fixed added filtration: 0.8mmAl)
Display method	LCD Display
X-ray field	55mm (Round style)
Battery	Lithium polymer battery (DC24V)
Charger Input	100~240V, 50~60Hz, 1.0A
Charger Output	DC25.2V, 0.75A)

Features
★Only 3.9 pounds(1.8kg) for optimum hand-held use
★The least radiation exposure but excellent image quality
★Micro-computer and specialized circuit that monitors and precisely regulates the exposure technique factors (kV, mA and exposure time)
★Simple up and down arrows adjust exposure setting by 0.01 seconds (0.01~1.60 sec.).
★The X-ray generator has been newly designed to reduce the volume and weight. (Patent acquisition)
★Uniquely designed internal lead shield protects the operator and the patient from dispersed radiation.
★Pre-programmed exposure time makes operation fast and easy
