• Model NO.：XR-16
• Transport Package：Metal Case; Carton Box
• Specification：Package size: 38x35x25 cm
• Trademark：DIO
• Origin：Korea
• HS Code：90184990
• Production Capacity：500units,Month

Basic Info.

Model NO. XR-16 Transport Package Metal Case; Carton Box Specification Package size: 38x35x25 cm Trademark DIO Origin Korea HS Code 90184990 Production Capacity 500units/Month

Product Description

Korea Original DIO Professional Digital Portable Dental X-ray Machine
Technical Data


Tube voltage	60kV (Fixed)
Tube current	2mA (Fixed)
High voltage generator circuit	High frequency Inverter method
X-ray control method	Controlled by the micro processor
Time setting range	0.01~1.60 second (0.01 sec step)
X-ray tube Type	Stationary anode X-ray tube
X-ray tube model	D-081BS(Toshiba)
X-ray tube focal size	0.8mm
Target angle	20°
Total filtration	1.6mm Al (Inherent filtration: 0.8mmAl, Fixed added filtration: 0.8mmAl)
Display method	LCD Display
SSD	100/200mm
X-ray field	55mm (Round style)
Net Weight	1.8kg
Size of main body	135(W)×150(D)×175(H)mm
Battery	Lithium polymer battery (DC24V)
Charger Input	100~240V, 50~60Hz, 1.0A
Charger Output	DC25.2V, 0.75A)

Features

★Only 3.9 pounds(1.8kg) for optimum hand-held use
★The least radiation exposure but excellent image quality
★Micro-computer and specialized circuit that monitors and precisely regulates the exposure technique factors (kV, mA and exposure time)
★Simple up and down arrows adjust exposure setting by 0.01 seconds (0.01~1.60 sec.).
★The X-ray generator has been newly designed to reduce the volume and weight. (Patent acquisition)
★Uniquely designed internal lead shield protects the operator and the patient from dispersed radiation.
★Pre-programmed exposure time makes operation fast and easy
