Video Advertising Glass Wall High Brightness Transparent LED Display Screen
Luoyang Tianpeng Packaging Product Co., Ltd.- Tube Chip Color：Full Color
- Display Function：Video Display
- Pixel Pitch：3.91 X 7.81
- Pixel Configuration：1R,1G,1B
- Pixel Density：32768 Dots,M2
- Scanning Mode：1,16 Scan
Base Info
- Model NO.：SY3.91-7.8
- System Operating Platform：Win98,2000,Nt,XP
- Display Type：LED Video Display
- Application：Advertising, Shopping Guide
- IP Rating：IP30
- Certification：CE, RoHS, FCC
- Panel Size：1000mm*1000mm
- Transparency：75%
- Transport Package：Wooden Box or Flight Case
- Specification：CE, RoHS, FCC
- Trademark：SENY
- Origin：Shenzhen, Guangdong, China
- HS Code：8528591090
- Production Capacity：100000
Description
Video Glass High Brightness Transparent LED Display Screen Model No. SY3.91-5 SY3.91-7.8 SY7.8-7.8 SY7.8-15.6 SY10.4-10.4 SY15.6-15.6 SY25-25 Pixel Pitch(mm) 3.91x 5.2 3.91 x 7.8125 7.8125 x 7.8125 7.8125 x 15.625 10.4x 10.4 15.64 x 15.64 25 x 25 LED Type 1921 1921 2525 2525 2525 3535 3535 Pixel Configuration 1R1G1B 1R1G1B 1R1G1B 1R1G1B 1R1G1B 1R1G1B 1R1G1B Brightness(CD/sqm) 5500 5500 5500 5000 5000 5000 4000 Driving Method(Scan) 16 16 8 8 3 4 4 Transparent Rate 60% 65% 68% 68% 75% 75% 80% Panel Size(mm) 1000*1000 1000*1000 1000*1000 1000*1000 1000*1000 1000*1000 1000*1000 Resolution Per Panel( dot ) 51200 32768 16384 8192 9216 4096 2500 Pixel Density(dot/sqm) 51200 32768 16384 8192 9216 4096 2500 Max. Power(w/sqm) 500 450 450 450 450 450 450 Ave. Power(w/sqm) 200 200 200 200 200 200 200 IP Protection IP30 IP30 IP30 IP30 IP30 IP30 IP30 Refresh Rate(HZ) 1920 1920 1920 1920 1920 1920 1920 Weight(KG/sqm) 15 15 14 14 13 13 12 Thickness(mm) 80 80 80 80 80 80 80 Working Temperature(ºC) -20-40 -20-40 -20-40 -20-40 -20-40 -20-40 -20-40
