Outdoor DIP Full Color Video Sign Board LED Advertising Panel for Shopping Guide
Luoyang Tianpeng Packaging Product Co., Ltd.- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：10mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display
- Average Power Consumption：450W,M2
Base Info
- Model NO.：SY-P10-4S-DIP
- Pixel Density：10000 dot , m²
- Scanning Mode：1,4 Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, RoHS, CCC, FCC
- Warranty：Two Years Warranty After Shipping
- Cabinet Size：960mm X 960mm
- Transport Package：Plywood Box or Flight Case
- Specification：CE, RoHS, FCC
- Trademark：SENY
- Origin：Shenzhen, Guangdong, China.
- HS Code：8528591090
- Production Capacity：5000sq. M,Month
Description
Outdoor DIP Full Color Video Sign Board LED Advertising Panel For Shopping GuideS/N Item Technical Parameters LED Parameters 1 Item Name LED Type Brightness Wave Length H/V Visual Angle 2 Red LED DIP346 1000-1100mcd 620-625nm 110º/50º 3 Green LED DIP346 2000-2200mcd 520-525nm 110º/50º 4 Blue LED DIP346 400-600mcd 470-475nm 110º/50º Module Specifications 1 Pixel Pitch 10mm 2 Pixel Configuration 1R1G1B 3 Module Resolution 16 x 16 pixels 4 Module Pixles 256 pixels 5 Module Size 160mm X 160mm Cabinet Specifications 1 Cabinet Size(W X H X D) 960mm x 960mm x 140mm 2 Cabinet Resolution(dot) 96 x 96 pixels 3 Module Quanity (pcs) 36pcs 4 Cabinet Pixels 9216 pixels 5 Pixel Density 10000 pixels/m2 6 Cabinet Materials Iron or Aluminum Whole Screen Specifications 1 Screen Brightness ≥7500cd/m2 2 Driving Method 1/4 scan 3 Mini Viewing Distance 10m 4 Max. Power Consumption 750W/m2 5 Average Power Consumption 450W/m2 6 Gray Level 8bits input, 4096 levels(212) 7 Display Color 16M 8 Frame Frequency ≥60Hz 9 Refresh Frequency ≥600Hz 10 Uninterrupted Working Hours ≥72 hours 11 Screen Life-span ≥100,000 hours 12 MTBF ≥5,000 hours 13 Discrete Blind Spot Rate <1/10000 14 Continuous Blind Spot Rate None 15 Blind Spot Rate <1/10000 16 Protective Scale IP65 17 Screen Plainness <±1mm 18 Power Supply Mode AC220±10% 50Hz/AC110±10% 60Hz 19 Environment Temperature & Humidity Temperature:-20 Celsius~+60 Celsius
Humidity:10%~90% RH 20 Control Mode Synchronous display with control PC by DVI 21 Control System DVI video card + full color control card + fiber system( optional) 22 Display Content Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. 23 Interface Standard Ethernet 24 Transmission Distance Multi mode fiber <500m, single mode fiber <30km,internet cable <100m
Packaging and delivery:
Humidity:10%~90% RH
