4000kgs Weight 2 Post Vehicle Ramp Hydrauclic Car Lift (209C)

Octopus Packing Material Technology (Changzhou) Co., Ltd
  • Type：Double Cylinder Hydraulic Lift
  • Lifting Capacity：4T
  • Driving Type：Hydraulic
  • Certification：CE
  • Driving Motor Number of Mechanical Lift：1
  • Double Cylinder Lift Type：Planer-type

Base Info

  • Model NO.：209C
  • Condition：New
  • Brand：Peak
  • Design：Two Post
  • Lifting Time：52 Seconds
  • Lifting Height：1815-2044mm(71 1,2" - 80 1,2")
  • Motor：2.0,3.0HP
  • Gross Weight：673kg(1,483lbs)
  • Color：Blue
  • Surface Treatment：Spray-Paint
  • Transport Package：Iron Bracket
  • Specification：9000LBS
  • Trademark：PEAK
  • Origin：Foshan, China
  • HS Code：8425429000
  • Production Capacity：30000sets,Year

Description

ModelLifting Capacity209C4.0T (9,000 lbs)209CH4.0T (9,000 lbs)2104.5T (10,000 lbs)210C4.5T (10,000 lbs)210CX4.5T (10,000 lbs)210SAC4.5T (10,000 lbs)211C5.0T (11,000 lbs)211CH5.0T (11,000 lbs)2125.5T (12,000 lbs)212C5.5T (12,000 lbs)215C6.8T (15,000 lbs)* "C" is clean-floor style.
* 209CH is higher than 209C.

Feature
• 9,000 Lbs Capacity
• Dual hydraulic cylinders, designed and made on ANSI standard, high quality NOK seals.
• 3/8" aircraft quality cable is used for synchronization.
• Supersymmetric arms design with three-stages front arms and two-stages rear arms.
• Self-lubricating UHMW Polyethylene sliders and bronze bush.
• Single-point safety release, and dual safety design.
• Clearfloor design, provide unobstructed floor space.
• Overhead safety shutoff device.
• Stackable rubber pad with 1.5", 2.5" and 5" extension adaptors.
• Automatic arms restraints.
• Hydraulic power unit.
• Long warranty period:
  5 Years warranty on lift structure(including Columns, Carriage, Lifting Arms, Top        Beam, Floor Cover, Platform, Cross Beam, Car Drive-in Ramp, Scissor, Baseframe etc.);
  2 Years warranty on the hydraulic parts (including cylinders, oil seal, oil hose, fitting etc.);
  1 Year warranty on the spare parts, electrical components, power unit (not including      consumption parts such as rubber pad).



4000kgs Weight 2 Post Vehicle Ramp Hydrauclic Car Lift(209C)Model209CStyleClean-floor Direct-drivedLifting Capacity4.0T (9,000lbs)Lifting Time52 SecondsALifting Height1815-2044mm (71 1/2" - 80 1/2")BOverall Height3621mm/3821(141 1/2" / 150 1/2")COverall Width3428mm(135")DDrive-Thru Clearance2528mm(99 1/2")EWidth Between Columns2850mm(112 1/4")FMinimum Pad Height90mm(3 1/2")Gross Weight673kg(1,483lbs)Motor2.0/3.0HPPacking Dimension2815 X 450 X 755 mmQTY of Container25 Units/20'GP50 Units/40'GP
