Mxl, XL, L, H Type Msm Standard Bore Timing Pulley
Heavybao Commercial Kitchenware Co., Ltd.- Application：Motor, Electric Cars, Motorcycle, Machinery, Marine, Agricultural Machinery, Car, Medical Machinery
- Hardness：Hardened Tooth Surface
- Gear Position：External Gear
- Manufacturing Method：Rolling Gear
- Toothed Portion Shape：Double Helical Gear
- Material：Aluminium Alloy
Base Info
- Model NO.：Keyless Pulley
- Type：Circular Gear
- Model Number：H
- Surface Color：Clear, Black, Silver
- Shape：Shape E, F
- Transport Package：Polyethylene Bag or Oil Paper for Each Item; Pile
- Specification：14-- 50 Tooth Number
- Trademark：HeFa
- Origin：Shenzhen China( Mainland)
- HS Code：84839000
- Production Capacity：500000 PCS, Year
Description
How to order* You send us drawing or sample * We carry through project assessment * We give you our design for your confirmation * We make the sample and send it to you after you confirmed our design * You confirm the sample then place an order and pay us 30% deposit * We start producing * When the goods is done, you pay us the balance after you confirmed pictures or tracking numbers. * Trade is done, thank you!! Applications Toy, Automotive, instrument, electrical equipment, household appliances, furniture, mechanical equipment,daily living equipment, electronic sports equipment, , sanitation machinery, market/ hotel equipment supplies, etc.
Packaging and Delivering:
Technical Profile:Part Number [ M ] Material [ S ] Surface Treatment Belt Width 19.1mm
(3/4inch) Belt Width 25.4mm
(1inch) Belt Width 38.1mm
(1.5inch) Belt Width 50.8mm
(2 inches) Pulley Flange Bushing Pulley Flange Bushing A: 21W: 26 A: 27W: 32 A: 40W: 45 A: 54W: 59 AW_ _HK191 AW_ _HK254 AW_ _HK381 AW_ _HK508 Aluminum Alloy 6061 1045 Carbon Steel Clear Anodize - SF_ _HK191 SF_ _HK254 SF_ _HK381 SF_ _HK508 1045 Carbon Steel Low Carbon Steel 1045 Carbon Steel Black Oxide SN_ _HK191 SN_ _HK254 SN_ _HK381 SN_ _HK508 Electroless Nickel Plating Part Number Pulley
Shape dH7 Range (Select Shaft Bore Dia. from Table 1) P.D. O.D. F E HK191 HK254 HK381 HK508 Type Teeth Type, Nominal Width EShape FShape EShape FShape EShape FShape EShape FShape AW
SF
SN 14 HK191
*A: 21
*W: 26
HK254
*A: 27
*W: 32
HK381
*A: 40
*W: 45
HK508
*A: 54
*W: 59
E
F 12~17 12~17 12~17 12~17 15~17 15~17 16~17 16~17 56.60 55.22 61 45 15 14~20 14~20 14~20 14~20 15~20 15~20 16~20 16~20 60.64 59.27 67 50 16 14~25 14~25 14~25 14~25 15~25 15~25 16~25 16~25 64.68 63.31 70 56 17 68.72 67.35 80 60 18 72.77 71.39 19 14~32 14~32 14~32 14~32 15~32 15~32 16~32 16~32 76.81 75.44 87 67 20 80.85 79.48 87 67 21 14~35 14~35 15~35 15~35 16~35 16~35 84.89 83.52 95 75 22 88.94 87.56 24 19~35 19~32 19~35 19~32 19~35 19~35 19~35 19~35 97.02 95.65 104 84 25 19~42 19~42 19~42 19~42 19~42 19~42 101.06 99.69 111 90 26 20~42 20~32 20~42 20~30 20~42 20~42 20~42 20~42 105.11 103.73 28 113.19 111.82 123 102 30 121.28 119.90 127 105 32 20~48 20~48 20~48 20~48 129.36 127.99 135 115 34 20~50 20~50 20~50 20~50 137.45 136.07 144 125 36 20~50 20~50 145.53 144.16 152 130 38 - 25~42 - 153.62 152.24 165 140 40 161.70 160.33 170 150 42 169.79 168.41 180 155 44 177.87 176.50 190 170 48 194.04 192.67 205 180 50 202.13 200.76 210 1 dH7 Max. Allowable Torque Nm D (L) ST Bushing SH Bushing ST Bushing SH Bushing 12 48 23 32 31 10.5 14 73 37 35 36 12 15 78 39 36 37 16 83 42 37 38 13 17 88 45 38 39 18 154 48 43 40 14 19 163 49 45 42 20 171 97 46 46 22 186 110 48 47 24 206 121 50 49 25 216 124 52 51 28 353 141 54 53 15.5 30 382 149 57 56 32 412 163 59 58 16.5 35 451 173 63 61 38 686 - 70 - 19 40 725 71 42 757 74 20 45 1490 84 24.5 48 1600 87 50 1660 89
