• Model NO.：GD150BF
• Production Capacity：25sets,Year

Basic Info.

Model NO. GD150BF Production Capacity 25sets/Year

Product Description

GD150BF Flat Lollipop Depositing Line with PLC control

FEATURES:
The processing line is a compact unit which can continuously produce various kinds of lollipop under a strict sanitary condition. It is also an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.

1. PLC /computer process control available;
2. An LED touch panel for easy operating;
3. The standard production capacity is 100~150kg/h;
4. The main parts is made of hygienic Stainless Steel
5. Optional (mass) flowing controlled by Frequency inverters ;
6. In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;
7. Dosing pumps for the automatic injection of colors, flavors and acids;
8. Use  AUTOMATIC STEAM CONTROL SYSTEM instead of manual steam valve which controls a stable steam supply to the microfilm cooker;
9. "two-color stripe depositing", "two-color double layers depositing", "central filling", "clear" lollipop and etc. can be made.
10. Moulds can be made according to the lollipop samples provided by the customer.

CANDY SAMPLES:

TECHNICAL SPECIFICATIONS:


Model	GD150BF
Output(kg/h)	150
Max lollipop weight	As per the lollipop size
speed	25~30 n/min
Steam consumption Steam pressure	250kg/h, 0.5~0.8MPa
Compressed air consumption Compressed air pressure	0.2m3/min, 0.4~0.6MPa
Electric power needed	18kW/380V
Total length(m)	15
Gross weight	3500 kgs
