CNC Steel Fiber Laser Cutting Machine
Xingyuan Plastic Manufacturing Co., Ltd- Application：Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Food Machinery, Aerospace Industry, Automotive Industry
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Metal
- Structure Type：Gantry Type
- Laser Classification：Semiconductor Laser
Base Info
- Model NO.：GS-3015
- Laser Technology：Laser Fusion Cutting
- Model No：GS-3015
- Laser Type：Fiber Laser
- Working Area：3000mm*1500mm
- Certification：Ce, ISO9001, SGS
- Customized：Customized
- Material：Metal
- Transport Package：Packaged by Plywood
- Specification：CE, SGS
- Trademark：GLORYSTAR
- Origin：China
- HS Code：8456100090
- Production Capacity：5000 Sets,Year
Description
Model No
GS-3015
Laser Type
Fiber Laser
Working Are
3000mm*1500mm
Laser Wavelength
1060 nm
Rated Output Power
500W/1000W
Beam Quality
<0.373mrad
X axis Travel Distance
3030mm
Y axis Travel Distance
1520mm
Z axis Travel Distance
105mm
Cooling Type
1HP Water Cooling
Repeat Positioning Accuracy
≤±0.02mm/m
Maximum Load of Worktable
800KG
Working Voltage
3 phase 380V / 50Hz / 100A
Main Power Protecting Level
IP54
Maximum Cutting Speed
30m/min
Minimum Line Width
0.15mm
Maximum Cutting Thickness
10mm
G.W.
4.5T
Service&Supports
1- Fast response to customer's request .
2- One year warranty , lifetime service, and supply parts at low price .
3- Supply the necessary video for assisting customer to intall and utilize the machine, on line assistant.
4- We are able to train the technicians & operators in Glory Laser or in customers' places .
Company Informations
1- 13 Years experience in manufacturing laser equipments.
2- Glory Laser exports to over 70 countries & regions .
3- Hold "NATIONAL HI-TECH Enterprise" certificate from China.
4- Optical Research Base Of Nanyang University.
