Type
CP-50HL
CP-55HL
CP-60HL
CP-65HL
Suitable raw material
HDPE  LDPE  LLDPE
Film width
200-600mm
400-800mm
500-1000mm
600-1200mm
Film thickness
HDPE
0.009-0.05mm
0.009-0.1mm
0.009-0.1mm
0.009-0.1mm
LDPE
0.02-0.1mm
0.03-0.1mm
0.03-0.1mm
0.03-0.1mm
Max.extrusion output
HDPE
50kg/hr
55kg/hr
65kg/hr
70kg/hr
LDPE
55kg/hr
65kg/hr
70kg/hr
75kg/hr
Extruding unit

Screw diameter
Φ50
Φ55
Φ60
Φ65
Screw L/D length
30:1
Cylinder material
Bi-Metallic/SACM-645 with nitrided treatment
Cylinder cooling
370W*3
370W*3
370W*3
370W*3
Temperature control
3 groups
3 groups
3 groups
3 groups
Extruding motor
15kw
18.5kw
22kw
30kw
