1.Overall parameters

Drilling depth

200m

Maximum open hole caliber

400mm

End hole caliber

75mm

Diameter of drill rod

50mm

Drilling angle

90~75

Weight(not include power)

760kg

Dimension

2750*950*1600mm

2. Vertical shaft

Rotating speed

71,142, ,310,,620r/min

Feeding stroke

450mm

3.Hoist

Max. single line hoisting capacity

2400Kg

Diameter of wire rope

13mm

Volume of winding drum

35m

Hug floodgate caliber

230mm

Hug floodgate belt width

70mm

4.Mud pump

Type

Horizontal single urn twin-action

Rate of flow

180L/min

MAX. pressure

1.5MPa

Working pressure

0.7MPa

Diameter of  water inlet tube

50mm

Diameter of  water outlet tube

45mm

5.Power

Diesel engine

22HP, 2200r/min

Delivery time : depends on the quantity, usually it is 10 working days.
Quality control : we have QC department, before shipping, goods will be strictly checked.
Tech support :
- 24 hours * 7 days online pre & after sale service ;
- Factory site training or engineers go to overseas to train the workers ;
- Manual and DVD operation video.
Spear parts: offer spear parts all year around at factory price.

Sales Manager:  Debbie Liu
