Data

Max. clamping force

KN

700

Max. opening force

mm

290

(V×H)Space between tie bars

mm

320x320

(min-max)

Mould height

mm

100-300

Max. daylight

mm

590

Ejector force

KN

25

Ejector stroke

mm

60

Ejector quantity



1

Screw diameter

mm

32

35

95

Screw L/D ratio

L/D

20

18.8

19.9

Theoretical shot volume

cm 3

112.5

135

287

Plasticising weight(PS)

g

101

121

261

Injection pressure

l Kg/cm

232

194

1640

Theoretical injection rate(PS)

g

62

72

499

Screw torque

N.m

390

Max. screw rotate speed

r/min

220

Injection stroke

mm

140

Pump motor power

KW

9

Pump pressure

KG/cm

16

Heating power

KW

6.2

Heating zone



4

Size

m

3.55×1.2×1.6

Net weight

t

2.7

International designation



700-230
