PE,PP,ABS... Max container capacityL10000 Output(dry cycle)pc/hr120 Machine dimension(L×W×H)M14.0×8.0×12 Machine weightT200 Clamping Unit   Clamping forcekn4000-5000Mold platen size(W×H)mm3200×3000 Platen moving strokemm2500-5500 Platen moving strokemm3000 Max Mold Size (WxH)mm3000×3200 Mold thicknessmm2600-2800 Power   Servo oil pump motor powerKW45*2 Servo pump displacementL/MIN250 Blow pressureMPA1 Air consumptionM3/MIN8 Cooling water pressurempa0.5 Water consumptionL/min100 Average energy consumptionKW85-100 Extruder unit   Screw diametermm120×2 Screw L/D ratioL/D30HDPE Melting capacit for HDPEkg/hr300-380 Number of heating zonezone6 Screw heating powerkw80 Screw fan powerKW0.6 Extruder motor powerkw132×2 Die head   Number of heating zone for single die headzone6 Heating power for single die headkw39 Max die-pin diametermm550 Accumulator capacityL600(HDPE) Accumulator weight(HDPE)KG450
Delivery Time:
- No later than 90 days after receipt of the deposit

Training:
- We provide training service for two or three operating men for free (but the cost for trainer's board and lodging is not included).

Installation:
- The supplier will send one specialist to test run the machine until it is running in normal state.

Guarantee:
- Our guarantee is valid for a period of 12 months. If the malfunction caused of the machine's self quality, we will troubleshoot it for free.

Auxiliary Equipments:
- Auxiliary equipments for production line are available and optional, please kindly ask for quotation.
