PE,PP,ABS... Max container capacityL3000 Output(dry cycle)pc/hr150 Machine dimension(L×W×H)M9.5×5.8×7.5 Machine weightT65 Clamping Unit   Clamping forcekn1200-1500Mold platen size(W×H)mm1950×1950 Platen moving strokemm1200-3400 Platen moving strokemm2200 Max Mold Size (WxH)mm1700×2200 Mold thicknessmm1250-1450 Power   Servo oil pump motor powerKW37 Servo pump displacementL/MIN200 Blow pressureMPA1 Air consumptionM3/MIN3 Cooling water pressurempa0.5 Water consumptionL/min100 Average energy consumptionKW100-120 Extruder unit   Screw diametermm120 Screw L/D ratioL/D30HDPE Melting capacit for HDPEkg/hr350-420 Number of heating zonezone6 Screw heating powerkw39 Screw fan powerKW0.6 Extruder motor powerkw110 Die head   Number of heating zone for single die headzone6 Heating power for single die headkw39 Max die-pin diametermm550 Accumulator capacityL80(HDPE) Accumulator weight(HDPE)KG60
Delivery Time:
- No later than 90 days after receipt of the deposit

Training:
- We provide training service for two or three operating men for free (but the cost for trainer's board and lodging is not included).

Installation:
- The supplier will send one specialist to test run the machine until it is running in normal state.

Guarantee:
- Our guarantee is valid for a period of 12 months. If the malfunction caused of the machine's self quality, we will troubleshoot it for free.

Auxiliary Equipments:
- Auxiliary equipments for production line are available and optional, please kindly ask for quotation.
