1.Overall parameters

Drilling depth

150m

Maximum open hole caliber

400mm

End hole caliber

75mm

Diameter of drill rod

50mm

Drilling angle

90~75

Weight(not include power)

810kg

Dimension

2750*950*1600mm

2. Vertical shaft

Rotating speed

142, 285, 570 r/min

Feeding stroke

450mm

3.Hoist

Max. single line hoisting capacity

1600Kg

Diameter of wire rope

11mm

Volume of winding drum

27 m

Hug floodgate caliber

230mm

Hug floodgate belt width

50mm

4.Mud pump

Type

Horizontal single urn twin-action

Rate of flow

95/77L/min

MAX. pressure

1.2MPa

Working pressure

0.7MPa

5.Power

Diesel engine

18HP, 2000r/min

Electrical motor

11KW, 1460r/min

Defy Service:
1.Professional technical support pre-sale, sale and after-sale .
2.Your problems can get feedback in 8 hours and be solved in 24 hours.
3.Machine can be customized as per your requirement.
4.One year quality warranty.
5.Training: operation manual and DVD operation video, overseas installation is also available.
6.Spare parts are available in our factory at cost price for former customers.

Complete list of drilling rig and drilling tools for your project. For more details, please kindly send us an inquiry or contact our sales people directly. Thank you!
