1. Model: SJ-A45 Film blowing machine
Diameter of screw: 45mm
L/D: 28: 1
Film thickness HD: 0.009-0.05mm
LD: 0.02-0.15mm
Reduced diameter of film: 100-500mm
Max. Output: 40-45kg/hr
Power of main motor: 7.5kw
Outline dimension: 5000*2000*4100mm2. Model: SJ-A50 Film blowing machine
Diameter of screw: 50mm
L/D: 28: 1
Film thickness HD: 0.009-0.05mm
LD: 0.02-0.15mm
Reduced diameter of film: 300-600mm
Max. Output: 45-50kg/hr
Power of main motor: 11kw
Outline dimension: 5000*2200*4500mm3. Model: SJ-A60 Film blowing machine
Diameter of screw: 60mm
L/D: 28: 1
Film thickness HD: 0.009-0.05mm
LD: 0.03-0.15mm
Max. Output: 65-70kg/h
Reduced diameter of film: 500-1000mm
Power of main motor: 18kw
Outline dimension: 5500*2600*6000mm4. Model: SJ-A65 Film blowing machine
Diameter of screw: 65mm
L/D: 28: 1
Film thickness HD: 0.009-0.05mm
LD: 0.03-0.15mm
Reduced diameter of film: 600-1200mm
Max. Output: 65-70kg/hr
Power of main motor: 22kw
Outline dimension: 5800*2800*6300mm
