Promotional Plastic PVC Drainage Pipe Production Machinery
Linyi Kunhong Tools Co., Ltd.Base Info
Description
SPECIFICATIONS FOR PVC DRAINAGE PIPE PRODUCTION MACHINERYModel Pipe spec(mm) Conical twin screw extruder Max.output
(kg/h) Total power(kw) GWG63-PVC Φ20-Φ63 GSZ65/132 180-300 104 GWG160-PVC Φ63-Φ160 GSZ65/132 180-300 105 GWG250-PVC Φ75-Φ250 GSZ80/156 300-450 110 GWG315-PVC Φ200-Φ315 GSZ80/156 300-450 216 GWG450-PVC Φ200-Φ450 GSZ92/188 650-750 290 GWG630-PVC Φ315-Φ630 GSZ92/188 750-850 350 GWG800-PVC Φ500-Φ800 GSZ135/31 950-1100 410 Model Motor power(kw) Screw diameter
(mm) Max.speed
(rpm) L/D Max.capacity(kg/h) Weight(kg) GSP75/28 37 75 36 28:1 280 4100 GSP93/13 45/55 93 45 31:1 450 4700 GSP110/31 90/110 110 45 31:1 680 6500 GSP120/31 110/132 120 45 31:1 850 7500 GSP135/31 160 135 45 31:1 1100 8400
For choosing the proper machine and saving your time, please read these bellow guides carefully
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (kg/h )
3). What is the max and min size of the finish products .For example, the width and thickness of sheet(mm)?
4) What is the electric device you need ? Siemens, Omron or domestic ?
5) When do you want the machine? (Times for delivery)
6) Other requirements about the machine you want.
if you are interested in this machine ,please contact me:
mob : +86 13915723896 ( or +86 13817556740 )
Jeremy He
(kg/h)
(mm)
(rpm)
| The vacuum tank | 2 CHAMBERS |
| Vacuum pump | 4KW x 2 set |
| Water pump | 4KW x 2 set |
| The material of the tank | Parts touched with water are made of stainless steel |
| The length | 8000mm |
| Stroke | 1000mm |
| ――Auto water level control | water temp and level, solenoid valves |
| ――Maximum pipe size | 200mm |
| ――Roller support for pipe | yes |
| Moving forward and backward | +/-500mm |
| Moving left and right | +/-40mm |
| Moving left and right | +/-60mm |
| Moving forward and backward motor | 0.75KW |
| ――Filter system for water | With parallel connection plastic filter |
For choosing the proper machine and saving your time, please read these bellow guides carefully
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (kg/h )
3). What is the max and min size of the finish products .For example, the width and thickness of sheet(mm)?
4) What is the electric device you need ? Siemens, Omron or domestic ?
5) When do you want the machine? (Times for delivery)
6) Other requirements about the machine you want.
if you are interested in this machine ,please contact me:
mob : +86 13915723896 ( or +86 13817556740 )
Jeremy He
