Basic Info.

Model NO. PPD-AEW740 Power 4.37kw Gross Weight 900kg Machine Dimension 1350X1350X1050mm Rewind Sub Roll Diameter Max145mm Transport Package Plywood Case Specification CE, SGS, ROHS Trademark PPD Origin China(Mainland) HS Code 84778000 Production Capacity 10units/Month

Product Description

Multi-function Automatic Extended Core Stretch Film Winding Machine is newly developed rewinding machine  technology upgraded based from Italy machine,after we amended the design,the machine is more for user friendly.
We have successfully applied the Patent from China,also some other countries patents we are pending.
it is very high speed,fully automatic rewinding, automatic paper core shaft exchange,PLC Program,lLCD Touch screen operating.less skilled operator request.suit for rewinding the extended core stretch film,pallet stretch wrapwrap,standard
stretch film,industrial stretch,wrapping film,food cling film etc.
One operator can run maximum 3 units of machines at the same
time,it reduce the prduction labor cost.

Technical Data:

Unwind parent roll width	Max 740mm
Unwind parent roll paper tube diameter	3inch
Unwind parent roll diameter	max 475mm
Rewind sub roll width	740mm
Rewind sub roll paper tube diameter	1.5''2''.3''(optional)
Rewind paper tube thickness	3mm-20mm
Rewind sub roll diameter	Max 145mm
Speed	Max1000m/min
Voltage	220/380/415v,3ph
Power	4.37kw
Machine dimension	1350x1350x1050mm
Gross weight	900kg

FAQ:
1 Q: Which machine do you require?
A: We have many models of machine, please contact our sales office who will assist you to select the best machine to suit your requirements.
2 Q: Can you make the machines as buyers' requests for us?
A:Yes. We have a professional RD team with rich experience to design and manufacturing.
3 Q: What is your terms of payment ?
A: T/T or L/C 30% deposit ,the balance after inspection and before shipment.
4 Q: How long is the warranty?
A: Machine with one year warranty, if any parts broken,we will send new spare parts to buyer via DHL within 24 hours,life-long maintenance
5 Q: How long is your delivery time?
A: 3 weeks for Standard model machine,30 working days for customized model.
6 Q:How do you pack the machine?
A: Free fumigation plywood cases
7Q:How do you deliver the machine?
A:By sea,by air,by road
8 Q: Will you support oversea service?
A: Yes, our engineer can go to buyer's factory to install the machine and train the operator for buyer.
We can also provide 2 days free training in our factory,with food and accommodation.
