• Model NO.：3HE-MF10W,30W marking machine
• Type：YAG Laser Marking Machine
• Marking Method：Scanning Marking
• Marking Model：3he-Mf10W,30W
• Marking Max. Output Power：10W,30W
• Marking Laser Wavelength：1064nm
• Marking Repeat Frequency：20-200kHz
• Standard Marking Range：110mmx110mm
• Optional Marking Range：75mmx75mm , 145mmx145mm
• Marking Depth：1.2mm
• Marking Speed：7000mm,S
• Marking Min. Line Width：0.01mm
• Marking Min. Chaaracter：0.1mm
• Transport Package：Carton Packing Marking Machine
• Specification：CE
• Trademark：SanHe
• Origin：Dongguan Guangdong
• HS Code：8486204900
• Production Capacity：200 Set Marking Machine,Month

Basic Info.

Model NO. 3HE-MF10W/30W marking machine Type YAG Laser Marking Machine Marking Method Scanning Marking Marking Model 3he-Mf10W/30W Marking Max. Output Power 10W/30W Marking Laser Wavelength 1064nm Marking Repeat Frequency 20-200kHz Standard Marking Range 110mmx110mm Optional Marking Range 75mmx75mm / 145mmx145mm Marking Depth 1.2mm Marking Speed 7000mm/S Marking Min. Line Width 0.01mm Marking Min. Chaaracter 0.1mm Transport Package Carton Packing Marking Machine Specification CE Trademark SanHe Origin Dongguan Guangdong HS Code 8486204900 Production Capacity 200 Set Marking Machine/Month

Product Description

-----What Can I Do ?
 Portable Laser marking machine is widely used in metal molds, the processing crafts , medical drugs , a single product Pipeline operations .

This kind of marking machine widely used in mobile phone shells , rings , bracelets , watches , mugs , glasses , watches , key , instrumentation , sanitary ware , home appliances , electronic components , integrated circuits , the cell phone button , luggage buckles , cutlery , water faucet , stainless steel products , car accessories , call phone chargers , cables and wires , and medical device industries marking.

------Material Application:

17-4 PH stainless steel	Magnesium
303 stainless	Metal-plated ceramics
4043 steel	Molybdenum
6061 Aluminum	Nickel plated 1215 mild steel
ABS (white/black)	Nickel plated brass
Aluminum, 6061	Nickel plated gold
Aluminum, yellow chromate	Nickel plated Kovar
Bayer 2807 Makrolon polycarbonate	Nickel plated steel
Bayers bayblend FR110	Nylon
Black/white ABS	PEEK, white
Brass	Polybutylene Terephthalate
Black/white polycarbonate	Polycarbonate (black/white)
Brushed aluminum	Polycarbonate resin 121-R, GE Plastics
Carbon fiber	Polycarbonate, Bayer 2807 Makrolon
Carbon nanotube	Polysulphone
Ceramics, metal-plated	Rynite PET
Clear coat anodized aluminum	Santoprene
Cobalt chrome steel	Silicon carbide
Colored delrin (black/brown)	Silicon steel
Compacted powder iron with phosphate coating	Silicon wafers
Copper	Stainless steel 303
DAP - Diallyl Phthalate	Stainless steel 17-4 PH
Delrin, colored (black/brown)	Steel 4043
GE Plastics polycarbonate resin 121-R	Steel, machine tool
Glass filled PEEK	Various inconel metals (nickel-chromium super alloys)
Glass filed Teflon	White PEEK
Hard coat anodized aluminum	Yellow chromate aluminum
Inconel metals (various)	Zinc plated mild steel
Machine tool steel	And Many More!

-----My Parameters :

Model	3HE-MF10W	3HE-MF30W
Max output power	10W	30W
Laser wavelength	1064nm	1064nm
Beam quality	m²<2	m²<2
Repeat frequency	20-200KHz	20-200KHz
Standard engraving range	110mm×110mm	110mm×110mm
Optional engraving range	75mm×75mm/145mm×145mm	75mm×75mm/145mm×145mm
Engraving depth	≤1.2mm	≤1.2mm
Marking speed	≤7000mm/s	≤7000mm/s
Minimum line width	0.01mm	0.01mm
Minimum character	0.1mm	0.1mm
Repeat accuracy	±0.002mm	±0.002mm
Electricity demand	220v±10%/50Hz/4A	220v±10%/50Hz/4A
Laser	Made in china/IPG	Made in china/IPG
Laser module life	>100000h	>100000h
Galvanometer	Made in china/imported	Made in china/imported
Cooling method	Air cooling	Air cooling

 If you have any questions,feel free to inquiry,we promise your problem will get our prompt reply!

Dedicated to serve you
Dongguan San He Laser Technology  Co., Ltd
Address:
Production Base of Sanhe Laser,B Bulding,YuFang Technology Park,Lianyi Industrial Park,Wentang Mid.
Road,DongCheng District DongGuan City,Guangdong Province

----------We are looking forward to coopereating with you ! ! !----------
