Hxh200 Highspeed Machine Produce Food Containers
Ningbo Beilun Daqi Hengxing Machinery Co., Ltd.Base Info
Description
TECHNICAL PARAMETER TABLEA B Screw diameter mm 45 50 Screw L/D ratio L/D 24 20 Injection capacity in theory cm3 341 422 Injection weight (Ps) g 311 384 Injection pressure MPa 199 161 Injection speed mm/s 260 Plasticizing Capacity g/s 28 40 Screw speed r/min 400 Clamping force kN 2000 Opening stroke mm 500 Max mold height mm 580 Min mould height mm 200 Space between tie-bar mm 570x520 Ejector force kN 80 Ejector stroke mm 150 Ejector No 9 9 Pump pressure MPa 17.5 Motor power KW 45 Heating power KW 16.8 Machine dimension m 6.34x1.56x1.93 Machine weight t 8.7 Oil tank capacity L 410
