Basic Info.

Model NO. SJ-L115-8 Engagement System Full Intermeshing Screw Channel Structure Deep Screw Exhaust Don′t Exhaust Automation Automatic Computerized Computerized Enter Attribute Here (e.g.: Size) Enter Value Here (e.g.: 12 Inches) Transport Package Wooden Cases Specification ISO9001: 2008 Trademark SANLONG Origin Wenzhou, Zhejiang, China HS Code 84778000 Production Capacity 36 Sets Per Day

Product Description

Main Features:
The machine using material of polypropylene & high density polyethylene, through heating extruding and drawing makes tape that is then winded for the weaving of the circular loom.
Performance and Characteristics:
Through our sustained improving , the machine can use 100% regenerated PP & PE ,powder or grain PP & HDPE to produce tapes .The screw and cylinder of extruder are of 38 CrMoAIA alloy steel, the hardness is over HV 950 after nitrogenation treatment. Helical gear reducer made of 20 CrMnTi Tially steel is applied to the extruder, the gears & chain wheels are made of 45# medium carbon steel and done the treatment of high frequency quench. The driving rollers are plated with hard Cr, tension self-controlling of winding-rollers are applied to the driving unit..
The cylinder of extruder, triton and die adopt aluminum cast heater which is endurable.
Main technical parameter:

Item Type	Diameter of  Screw (mm )	Screw L/D Ratio	Screw Rotational Speed (r/min)	Die Length (mm )	Drawing Line Speed (m/min )	Stretched Ratio	Prime Motor Power (kw )	Drawing Motor Power ( kw )	Heating Power (kw )	Thickness of Plastic Tape (mm )	Capacity (kg/h)	Installation Dimension (m )	Weight(kg)
SJ-L115-8	115	22/27	20-80	800	50-150	4-7	18.5	5.5	48	0.025-0.08	40-80	14.1×1.55×1.2	5800
SJ-L120-10	120	23/29	20-80	1000	50-150	4-7	22/37	5.5	50/54	0.025--0.08	70-100	18.1×1.75×1.3	7500
SJ-L120-12	120	24/30	20-80	1200	50-150	4-7	22/37	7.5	52/56	0.025--0.08	80-110	18.1×2×1.3	8500
SJ-L132-15	132	24/30	20-80	1500	50-150	4-7	30/37	7.5	57/61	0.025--0.08	105-135	19.5×2.4×1.3	10500
SJ-L135-16	135	26/30	20-70	1600	50-150	4-7	30/45	7.5	61/65	0.025--0.08	130-160	19.6×2.6×1.3	11200
SJ-L140-18	140	27/30	20-70	1800	50-150	4-7	37/45	11	71/75	0.025--0.08	150-180	19.9×2.95×1.3	12800
SJ-L145-20	145	27/30	20-70	2000	50-150	4-7	45/55	11	75/81	0.025--0.08	170-200	20.1×3.25×1.3	14000
SJ-L150-22	150	27/30	20-70	220	50-150	4-7	45/55	11	86/90	0.025-0.08	190-225	20.4×3.85×1.35	15300
SJ-L155-24	155	27/31	20-65	2400	50-150	4-7	55/75	11	90/94	0.025-0.08	205-235	20.8×4.2×1.35	16800
SJ-L155-26	155	27/32	20-65	2600	50-150	4-7	55/75	15	98/103	0.025-0.08	220-250	21×4.55×1.35	18600
SJ-L160-28	160	27/32	20-65	2800	50-150	4-7	55/75	15	106/112	0.025-0.08	240-270	22×4.75×1.4	21000
SJ-L165-30	165	27/32	20-65	3000	50-150	4-7	75/90	15	114/120	0.025-0.08	260-300	22.5×5.05×1.4	23500
SJ-L170-32	170	28/32	20-65	3200	50-150	4-7	75/90	18.5	122/128	0.025-0.08	290-350	22.8×5.05×1.7	26000
