Hydraulic Pump Bent Axis Fixed Displacement Pumps 28cc
Guangzhou Sundy Commercial Co., Ltd.- Certification：CE, ISO9001
- Pressure：High Pressure
- Work Temperature：Normal Temperature
- Voltage：220V
- Installation：Vertical
- Material：Cast Steel
Base Info
- Model NO.：A2F028
- Transport Package：in Plywood Case
- Specification：CE, ISO
- Trademark：HYPHEN
- Origin：China, Jiangsu
- HS Code：8413603290
- Production Capacity：5000PCS,Year
Description
Technical Data
Size
12 23 28 56 80 107 160 Output(input)Displacement
Vg ml/r 12.0 22.9 28.1 56.1 80.4 106.7 160.4 Max.Speed Close Circuit
nmax r/min 6000 4750 4750 3750 3350 3000 2650 Open Circuit at0.09MPa no0.09 r/min 2980 2370 2370 1890 1705 1515 1375 at0.10MPa no0.10 r/min 3150 2500 2500 2000 1800 1600 1450 at0.15MPa no0.15 r/min 3760 2985 2985 2390 2150 1910 1730 Max.Output
(input)Flow Close Circuit
Qmax l/min 72 109 133 210 269 320 425 Open Circuit no0.09 Po0.09 l/min 35 53 65 104 134 158 216 no0.10 Po0.10 l/min 37 56 69 110 142 167 228 no0.15 Po0.15 l/min 44 67 82 131 169 200 272 Max.Power
ΔP=35MPa
(Keyed
shaft end) Close Circuit atQmax Pmax kW 42 64 78 123 157 187 248 Open Circuit atQo0.09 Po0.09 kW 21 32 39 62 80 94 129 atQo0.10 Po0.10 kW 22 33 41 65 85 99 136 atQo0.15 Po0.15 kW 26 40 49 78 101 119 162 Drive Speed
ne=1450r/min Output(input)Flow Close Q l/min 17 33 41 81 117 155 233 Open Q l/min 17 33 40 80 114 152 228 PowerΔP=35MPa close+open P kW 10 19 24 47 68 90 136 Torque ΔP=10MPa
M N.m 19 36 45 89 128 170 255 ΔP=35MPa
Mmax N.m 67 127 156 312 447 594 893 Moment of Inertia about drive axis
J kgm² 0.0004 0.0012 0.0012 0.0042 0.0072 0.0016 0.022 Weight
m kg 6 9.5 9.5 18 23 32 45
