Horizontal Directional Drilling Rig OS20
Dongguang Shengrui Packaging Machinery Co., Ltd.Base Info
Description
Diesel EngineModel Cummins 6BT5.9-C150 Power 110KW@2300r/min Cylinders 6 Cooling Type Water Cooling Rotation Gears 2 Low Speed Speed of Rotation 60 RPM Torque of Spindle 6 000 Nm High Speed Speed of Rotation 120 RPM Torque of Spindle 3 000 Nm Thrust and Pullback Move Speed 2 Low Speed Force of Thrust 200 KN Force of Pullback 200 KN High Speed Force of Thrust 90 KN Force of Pullback 90 KN Other Parameters Drilling Angle 0-25º Power Winch Jaws Clamping Spindle Torque 6 000 Nm Jaws Reducing Spindle Torque 12 000 Nm Mud Pump Maximum Capacity 240 L/min Maximum Pressure 7 Mpa Drill Rod Length 3 000mm Rod Lock Φ73 mm Rod Body Φ60 mm Max Bending 5% Total Weight 7 800 Kg Dimensions Main Machine (L×W×H) 5500x2200x2100mm
