Omrs125 Hyd Motor (eaton char-lynn S-series hydraulic motor)

Guangzhou Cospack Packaging Technology Co., Ltd.
  • Certification：CE, ISO9001
  • Type：Hydraulic Motor
  • Code：Omrs 36,50,80,100,125,160,200,250,315
  • Max Speed：Contin155~1250rpm
  • Max Torque：Contin 72~365 N.M
  • Output Shaft：25mm,32mm,25.4mm Parallel Key, Splined Key

Base Info

  • Model NO.：omrs125
  • Flange：Circle-Flange, Rhomb-Flange
  • Motor of Material：Cast Iron
  • Replace：Danfoss, Eaton, M+S, Parker
  • Assignment Forms：Axial Flow
  • Fuel：Synthetic Hydraulic Fluid
  • Item：Hydraulic Power Unit
  • Transport Package：Sale Packing Contians Carton or Wood Case
  • Specification：CE
  • Trademark：Blince
  • Origin：Guangdong, China (Mainland)
  • HS Code：8412291000
  • Production Capacity：1000000 PCS,Year

Description

Type OMRS36OMRS50OMRS80OMRS100OMRS125OMRS160OMRS
200OMRS
250OMRS
315OMRS
375Displacement
(cc/rev)3651.781.5102127.2157.2194.5253.3317.5381.4Max speed
(rpm)
 cont1250960750600475378310240190155int15201150940750600475385300240190Max torque
(N/m)cont72100195240300360360390390365int83126220280340430440490535495peak105165270320370460560640650680Max. output (kW)cont8.59.512.513.012.512.510.07.06.05.0int9.811.215.015.014.514.013.09.59.08.0Max
Pressure
drop
(Mpa)cont14.014.017.517.517.516.513119.07.0int16.517.52020202017.5151310peak22.522.522.522.522.522.522.52017.515Max flow
(L/min)cont40506060606060606060int45607575757575757575Net Weight (kg)6.56.76.97.07.37.68.08.59.09.5
BLINCE OMRS hydraulic motor
 Model:
36cc,50cc,80cc,100cc,125cc,160cc,200cc,250cc,315cc,375ccMounting Flange:H2: 2-Ø13.5Rhomb-flange, pilot Ø82.5×2.8
H6: 4-Ø13.5Rhomb-flange, pilot Ø82.5×2.8
H4: 4-3/8-16 Square-flange, pilot Ø44.4×2.8
H5: 4-M10 Square-flange, pilot Ø44.4×2.8Output Shaft:K: Shaft Ø25.4,Woodruff Key Ø25.4×6.35
S: Sub-shaft Ø25.4,splined toothSAE 6B
A: Shaft Ø25 , parallel key 8×7×32
R: Shaft Ø25.4, parallel key 6.35×6.35×31.75
H: Sub-shaft Ø25.4,Pin hole Ø10.3
H1: Shaft Ø25.4, pin hole Ø8
D: Shaft Ø22.22, parallel key 6.35×6.35×25.4
I: Shaft Ø22.22, splined tooth13-DP16/32
T2: Cone shaft Ø25.4 , woodruff key Ø25.4×6.35
P: Shaft Ø25,parallel Key 8×7×28
J: Shaft Ø25,parallel Key 7×7×32Ports and Drain Port:G: G1/2, G1/4
S: 7/8-14 O-ring 7/16-20UNF(G1/4)
P: 1/2-14 NPTF, 7/16-20UNF(G1/4)
T: 3/4-16 O-ring, 7/16-20UNF
R: PT(Rc)1/2, PT(Rc)1/4
B4:Ø10 O-ring manifold 4x5/16-18, 7/16-20UNF
B5: Ø10 O-ring manifold 4xM8, G1/4
M1: M18×1.5, M10×1
M2: M20×1.5, M10×1
M3: M22×1.5, M10×1Rotary DirectionStandard
Reverse
Application areas:
* Sweeper
* Hydraulic Winch
* Conveyor
* Crane
* Aerial lift
* Combine Harvester
* Seeder
* Spreader
* Auger
* Machine tool
* And more
