PP/PE/PS/ABS  Sheet  machine, PP sheet making machine, PS sheet production machine, PE sheet extrusion machine, ABS sheet production lineSingle screw extruderadopts long L/D, high efficiency screw, high extrusion capacity, uniformed plasticization. Extruder and haul off machine motors adopt imported AC/DC inverter as speed regulators.Vacuum Feeding MachineFeeding Capaity:  Max 350kg/h
T-type Die Head

 Die Head Material: 5CrNiMo
Brands: JC-times,.


Three Roller CalendarMotor power: 1.1kw*3 sets, with ABB frequency inverter
Roller Diamter: 350-450mm,
Roller Wall thickness: 35mm
Cooling Frame and Edge Trimming Unit
 Cooling Frame length: 6000mm
Edge trimming: 2 knives, position adjustable


Hual off Machine
 Haul off method: 2-rubber rollers
Motor: 3kw with ABB inverter


Cutting machine
 Guillotine-knife cutting machine or Twin position CoilerElectrical cabinet: ABB inverter, Shneider contator, RKC thermocontroller,
Siemens PLC, and etc.


PRODUCTION FLOWS:
Vacuum feeding machine>single screw extruder>hydraulic exchanger>T-die head>three roller calendars>thermoforming machine>cooling frame and edge cutting units>2 rubber rollers haul off machine>cutter-guillotine or twin position winder>material conveying able>stacker
