Project

Parameters

Chassis

Engine Type

Cum QSM11-C330

Engine Power/Speed

246/2100

Crawler Expansion Width (From The Outside)

4400

Crawler Board Width

800

Traction Force

520

Power Head

Max. Output Torque

260

Power Head Speed

6-25

Max.Pull-Down Piston Push

200

Max.Pull-Down Piston Pull

250

Pressurized cylinder Stroke

5000

Winch

Main Winch

Max.Line Pull of the first layer

280

Max.Line Speed

55

Wire Rope Diameter

32

Auxiliary Winch

Max.Line Pull of the first layer

80

Max.Line Speed

65

Wire Rope Diameter

20

Mast

Mast Forward Inclination

5

Mast Sideward Inclination

4

Hydraulic Pump

Max. Working Pressure

35

Depth and Diameter

Max. Drilling Diameter

2500

Max. Drilling Depth

80

Drilling Pipe

Drilling Pipe

508

Working State Quality

82

Project

Parameters

A

Working State Height

22269

Working State Width

4400

B

Transportation State Length

16165

C

Transportation State Height

3510

Transportation State Width

3300

D

Crawler Length

5816

E

4264

F

2275

G

1050
