20W Handheld Fiber Laser Marking Engraver Machine Deeper Advanced Precision
Foshan Zhentu Aluminum Co., Ltd.- Laser Visibility:Visible
- Applicable Material:Metal
- Cooling System:Air Cooling
- Technical Class:Continuous Wave Laser
- Laser Wavelength:Fiber Laser
- Laser Classification:Semiconductor Laser
Base Info
- Model NO.:LS-YLP-P20,30,50L
- Type:Optical Fiber Laser Marking Machine
- Marking Method:Scanning Marking
- Model:Ls-Ylp-20L
- Laser Power:20W;30W;50W
- Power Consumption:<500W
- Wavelength:1064nm
- Engraving Range:Max 400*400mm(Customized)
- Engraving Depth:1.2mm
- Minimum Line Width:0.012mm
- Minimum Character:0.1mm
- Repeated Accuracy:+-0.003mm
- Life of Laser Module:100000hrs
- Transport Package:Wooden Case
- Specification:980*800*1590
- Trademark:Lospeed or Customized
- Origin:China
- HS Code:8456100090
- Production Capacity:100 Sets , Month
Description
Basic Info.
Model NO. LS-YLP-P20/30/50L Type Optical Fiber Laser Marking Machine Marking Method Scanning Marking Model Ls-Ylp-20L Laser Power 20W;30W;50W Power Consumption <500W Wavelength 1064nm Engraving Range Max 400*400mm(Customized) Engraving Depth 1.2mm Minimum Line Width 0.012mm Minimum Character 0.1mm Repeated Accuracy +-0.003mm Life of Laser Module 100000hrs Transport Package Wooden Case Specification 980*800*1590 Trademark Lospeed or Customized Origin China HS Code 8456100090 Production Capacity 100 Sets / MonthProduct Description

20W Handheld Fiber Laser Marking Engraver Machine Deeper Advanced Precision
Introduction of Fiber Laser Marking Machine




Product Application Fiber Laser Marking Machine engraving stainless steel, brass, aluminum (iPhone, iPad ), gold, silver, titanium etc. laser engraving metal & plastic. China industrial fiber laser engraving machine manufacturer. Desktop laser engraving machine for metal laser engraving and plastics marking. Laser engraving logo, text, QR code, bar code, serial number etc.
Main Features
1. Laser power output is stable, and light spot quality is good.
2. Quick marking and cutting speed at 2-3 times that of conventional machines.
3. No pollution, no noise, and consumable materials, with power consumption
4.No need any maintenance,long life,samll volume, suit for working in atrocious conditions.
5. To easily fit into your production environment
Technical Parameters
Model | YLP-20J | YLP-30J |
Power | 20W | 30W |
Wavelength | 1064nm | 1064nm |
Beam Quality | M2<1.3 | M2<1.3 |
Output Power | 10%-100%(continuously to be adjusted) | 10%-100%(continuously to be adjusted) |
Output Frequency | 20KHz-100KHz(continuously to be adjusted) | 20KHz-100KHz(continuously to be adjusted) |
Power Stability(8h) | <±1%rms | <±1%rms |
Focus Spot Diameter | <0.01mm | <0.01mm |
Engraving Range | ≤400*400mm(customized) | ≤400*400mm(customized) |
Engraving Depth | 1.2mm | 1.2mm |
Engraving Speed | 800 standard characters/second | 800 standard characters/second |
Minimum Line Width | 0.012mm | 0.012mm |
Minimum Character | 0.1mm | 0.1mm |
Repeated Accuracy | ±0.003mm | ±0.003mm |
System Operation | Windows XP/2000/98 | Windows XP/2000/98 |
Cooling Mode | Air Cooling | Air Cooling |
Environment Temperature | 10ºC~35ºC | 10ºC~35ºC |
Environment Humidity | 20%-80% | 20%-80% |
Power Requirement | 220V/Singlephase/50Hz/<400W | 220V/Single phase/50Hz/<400W |
Life of Laser Module | 100000Hrs | 100000Hrs |
Host Size | 800mmx650mmx1435mm | 800mmx650mmx1435mm |
Electronic Components : | Resistance, capacitance, chips, printed circuit boards, computer keyboard. |
Apparatus And Meter: | Panel signs, precision equipment ,etc., |
Instrument: | Panel signs nameplates, precision equipment ,etc., |
Hardware Tools : | Knives, tools, measuring tool, cutting tool, etc., |
Automobile Parts : | Pistons, piston rings, gears, shafts, bearings, clutch, lights, etc., |
Mechanical Parts : | Bearings, gears, standard parts, motors, etc., |
Daily Necessities : | Handicrafts, zipper, key holder, sanitary ware, etc., |
Jewelry Rings: | Jewelry, gold, silver,etc. |
Food, drinking packing: | Plastic packings,etc. |

Packaging & Shipping
After - sales service
1. Warranty
2 years for the laser source. 1 year for the other machine parts.
2. Technical support
Lifelong technical support online or by email and 18 hours online service to help you use our machine well.
3.Tranining service
Offer training at our factory for free (you could visit us and learn)
Please advise us following inforamtion to recommend you most suitable machine:
1.What's kind of material do you want to mark? metal parts or non metal material?
2.What's the max working area do you need? we can provide you with 110*110mm, 175*175mm, and 220*220mm, 300*300mm, or customized as your demand.
Looking forward to your inquiry!
Your satisfication is our Honor.
