• Model NO.：OMT250
• Type：Hydraulic Actuator
• Size：Big
• Color：No Paint, Black, Iron Ash
• Material：Cast Iron
• Appliction：for Havy Machine
• Flang Shape：Square and Rhombus Flange
• Hydraulic Motor Shafts：Straight, Splined and Tapered
• Structural Style：Cycloid
• Motor Power：Hydraulic Oil
• Hydraulic Motor：Piston Hydraulic Motor
• Hydraulic Power Units：Screw Pump
• Transport Package：Plastic Tube +Carton+Wooden Pallets
• Specification：CE, CCC, ISO
• Trademark：Blince
• Origin：Dongguan, China
• HS Code：8412291000
• Production Capacity：1000 Per Month

Basic Info.

Model NO. OMT250 Type Hydraulic Actuator Size Big Color No Paint/ Black/ Iron Ash Material Cast Iron Appliction for Havy Machine Flang Shape Square and Rhombus Flange Hydraulic Motor Shafts Straight, Splined and Tapered Structural Style Cycloid Motor Power Hydraulic Oil Hydraulic Motor Piston Hydraulic Motor Hydraulic Power Units Screw Pump Transport Package Plastic Tube +Carton+Wooden Pallets Specification CE, CCC, ISO Trademark Blince Origin Dongguan, China HS Code 8412291000 Production Capacity 1000 Per Month

Product Description

Omt315cc/400/500/630CC/800cc Hydraulic Motors
BMT series motor adapt the advanced Gerolor gear set design with disc distribution flow and high pressure. The unit can be supplied the individual variant in operating multifunction in accordance with requirement of applications.
Characteristic features:
*  Advanced manufacturing devices for the Geroler gear set, which use low pressure of start-up, provide smooth and reliable operation and high efficiency .
*  The output shaft adapts in tapered roller beadrings that permit high axial and radial forces. Can offer capacities of high pressure and high torque in the wide of applications.
*  Advanced design in disc distribution flow, which can automatically compensate in operating with high volime efficiency and long life, provide smooth and reliable operation.


type	BMT	BMT	BMT	BMT	BMT	BMT	BMT	BMT	BMT
displacement	160	200	230	250	315	400	500	630	800
speed	625	625	536	500	380	305	240	196	154
torque	470	590	670	730	950	1080	1220	1318	1464
output	27.7	34.9	34.7	34.5	34.9	31.2	28.8	25.3	22.2
pressure	20	20	20	20	20	18	16	14	12.5
flow	100	125	125	125	125	125	125	125	125
weight	19.5	20	20.4	20.5	21	22	23	24	25

Applications :
Hydraulic motors are ideally suited for Applications demanding vary high Torque at low or variable speeds, along with economy, compact size, reliability, maintenance-free service etc. These motors also provide a cost effective alternative to many other variable speed drives in vogue.

Packaging details:
1. Industrial packing: plastic tube +carton+wooden pallets
2. Commercial packing: plastic bag +color box+wooden pallets
3. The transportation as per your request


Our company professional produce all kinds of hydraulic motors and related parts that can meet all your need. We have the experienced engineers to select the appropriate models for you.

Warranty:
1. Guarantee for one year or 1000 hours (according to whichever ends first) from the purchasing date on.
2. During the guarantee period, our company will provide the easy-damaged spare parts for problems caused by our
quality of production or raw material. Pls provide the defective appearance and related invoice number.
3. Sorry for you should responsible for the freight come-and-go,and the custom tax.
4. After expiration, our company can provides cost spare-parts maintenance for engines.
5. To save the cost,you can choose send the motor back without packing.
