Hydraulic Motor (with brake) Sphere Piston 1qjm21-0.5sez
Guangzhou Sundy Commercial Co., Ltd.- Type：Hydraulic Motor
- Hydraulic Valve：Switch Control Valve
- Auxiliary Components：Oil Temperature Gauge
- Hydraulic Fluid：Mineral Oil
- Flow Control Valve：Adjusting Valve
- Pressure Control Valve：Pressure Relay
Base Info
- Model NO.：1QJM01-0.2...SZ
- Hydraulic Control Unit：Selector Valve
- Hydraulic Motor：Piston Hydraulic Motor
- Hydraulic Actuator：Combination Hydraulic Cylinders
- Hydraulic Power Units：Piston Pump
- Transport Package：in Plywood Case
- Specification：ISO9001
- Trademark：Hyphen
- Origin：China
- HS Code：8412291000
- Production Capacity：3000PC,Year
Description
Technical data for Se,Sez series hydraulic with outside control brakeType ml/rev)
Displacement (MPa)Pressure (r/min)
Speed Range (N.m)
Output torque (MPa)
Brake start pressure Brake Torque Rated peak 1QJM12-0.8Se,Sez 0.808 10 16 4-250 1076 1.3≤P≤6.3 ≥1800 1QJM12-1.0Se,Sez 0.993 10 16 4-200 1332 1QJM12-1.25Se,Sez 1.328 10 16 4-160 1771 1/2QJM21-0.32Se,Sez 0.317 16 25 2-500 751,376 2.5≤P≤6.3 ≥2500 1/2QJM21-0.40Se,Sez 0.404 0.202 16 25 2-400 957,479 1/2QJM21-0.50Se,Sez 0.496 0.248 16 25 2-320 1175,588 1/2QJM21-0.63Se,Sez 0.664 0.332 16 25 2-250 1572,786 1/2QJM21-0.80Se,Sez 0.808 0.404 16 25 23-200 1913,957 1/2QJM21-1.0Se,Sez 1.01 0.505 10 16 2-160 1495,748 1/2QJM21-1.25Se,Sez 1.354 0.677 10 16 2-125 2004,1002 1/2QJM21-1.6Se,Sez 1.65 0.825 10 16 2-100 2442,1221 1/2QJM32-0.63Se,Sez 0.635 0.318 20 31.5 3-300 1880,940 ≥6000 1/2QJM32-0.8Se,Sez 0.808 0.404 20 31.5 3-250 2368,1184 1/2QJM32-1.0Se,Sez 0.993 0.497 20 31.5 2-250 3138,1569 1/2QJM32-1.25Se,Sez 1.328 0.664 20 31.5 2-200 3833,1942 1/2QJM32-1.6Se,Sez 1.616 0.808 20 31.5 2-200 4881,2441 1/2QJM32-2.0Se,Sez 2.03 1.355 16 25 2-200 4807,2404 1/2QJM32-2.5Se,Sez 2.71 1.055 10 16 1-160 4011,2006 1/2QJM32-3.2Se,Sez 3.3 1.65 10 16 1-125 4884,2442 1/2QJM32-4.0Se,Sez 4.0 2.0 10 16 1-100 5920,2960 1/2QJM42-2.0Se,Sez 2.11 1.055 20 31.5 1-250 6246,3123 2.1≤9≤6.3 ≥9000 1/2QJM42-2.5Se,Sez 2.56 1.28 20 31.5 1-250 7578,3789 1/2QJM42-3.2Se,Sez 3.3 1.65 10 16 1-200 4884,2442 1/2QJM42-4.0Se,Sez 4.0 2.0 10 16 1-160 5920,2960 1/2QJM42-4.5Se,Sez 4.56.28 10 16 1-125 6808,3404 1/2QJM52-2.5Se,Sez 2.67 1.355 20 31.5 1-200 7903,3952 2.2≤P≤6.3 ≥10000 1/2QJM52-3.2Se,Sez 3.24 1.62 20 31.5 1-200 9590,4795 1/2QJM52-4.0Se,Sez 4.0 2.0 16 25 1-200 9472,4736 1/2QJM52-5.0Se,Sez 5.23 2.615 10 16 1-160 7740,3870 1/2QJM52-6.3Se,Sez 6.36 3.18 10 16 1-125 9413,4707
Displacement
Speed Range
Output torque
Brake start pressure
