Full Needle Rnav Nav4015 4016 4017 Needle Bearing for Drive Gear Kit
Ruian Sowinpak. Co., Ltd.- Cage：With Cage
- Rows Number：Single
- Load Direction：Radial Bearing
- Style：Without Inner Ring, With Inner Ring
- Material：Bearing Steel
- Type：Closed
Base Info
- Model NO.：NAV4015
- Transport Package：as Your Request
- Specification：All size in stock
- Trademark：Edinh
- Origin：China
- Production Capacity：500000,20 Days
Description
Basic Load RatingsLimiting Diameter d F D B r Cr Cor Speed mm g min. kN kN rpm 15 NAV4002/RNAV4002 76 15 21.87 32 17 0.3 10.8 29.8 4500 17 NAV4003/RNAV4003 98 17 24.3 35 18 0.3 12.0 17.0 3400 20 NAV4004/RNAV4004 175 20 28.7 42 22 0.6 14.5 29.6 3000 25 NAV4005/RNAV4005 201 25 33.5 47 22 0.6 23.3 34.6 2600 30 NAV4006/RNAV4006 311 30 40.1 55 25 1.0 28.5 46.9 2000 35 NAV4007/RNAV4007 418 35 45.9 62 27 1.0 33.5 59.9 1800 40 NAV4008/RNAV4008 495 40 51.6 68 28 1.0 35.9 67.0 1700 45 NAV4009/RNAV4009 637 45 57.4 75 30 1.0 41.3 74.0 1500 50 NAV4010/RNAV4010 702 50 62.1 80 30 1.0 42.8 88.9 1400 55 NAV4011/RNAV4011 1030 55 69.8 90 35 1.1 48.9 109.0 1300 60 NAV4012/RNAV4012 1125 60 74.6 95 35 1.1 50.7 116.0 1100 65 NAV4013/RNAV4013 1200 65 80.3 100 35 1.1 59.4 126.0 1000 70 NAV4014/RNAV4014 1700 70 88 110 40 1.1 72.4 155.0 950 75 NAV4015/RNAV4015 1810 75 92.7 115 40 1.1 74.1 164.0 900 80 NAV4016/RNAV4016 2470 80 100.3 125 45 1.1 82.3 174.1 900 85 NAV4017/RNAV4017 2580 85 104.8 130 45 1.1 -- -- 900
K series needle roller bearings
.
K series needle roller bearings.
