Product Description

SF-2 SBoundary Lubricating Bushing

Product introduction

SF-2 boundary lubricating bushing is based on a composite material with 3 firmly bonded layers:steel as backing,sintered bronze sphericalpower as interlayer and modified POM as lining layer,It fits well for low speed,middle-load and normal temperature and saves cost and prolings working life when replacing normal all copper sleeves.It is widely applied in auto chassis,forging machine,matallurgical and mining machine,civil engineering,power station,strip rolling industries,etc.



The use of parameters

Parameters	SF-2 Marginal Bushing	SF-2Y Lead Free Marginal Bushing	SF-2S Lead Free Marginal Bushing	SF-2L Lead Free Marginal Bushing
Max Load capacity P(Dynamic)	140 N/mm²	140 N/mm²	140 N/mm²	140 N/mm²
Max Load capacity P(Static)	250 N/mm²	250 N/mm²	250 N/mm²	250 N/mm²
Max line speed V(Grease)	2.5 m/s	2.5 m/s	2.5 m/s	2.5 m/s
Max imum PV value(Grease)	3 N/mm².m/s	3 N/mm².m/s	3 N/mm².m/s	3 N/mm².m/s
Friction Coef. μ (Grease)	0.05~0.205	0.05~0.205	0.05~0.205	0.05~0.205
Working Temp.	-40ºC~+110ºC	-40ºC~+110ºC	-40ºC~+110ºC	-40ºC~+110ºC
Thermal conductibility	4W/m·k	4 W/m·k	4 W/m·k	4 W/m·k
Coefficient of linear expansion	11×10^-6/K	11×10^-6/K	11×10^-6/K	11×10^-6/K

Please contact us for a list of recommended specifications.If required specifications are not in the list,they can be customized for users.
