NSK High Super Precision 71822CD/P4 Angular Contact Ball Bearing
Kunshan Shenkai Precision Mould Co., Ltd.- Rolling Body：Roller Bearings
- The Number of Rows：Single
- Outer Dimension：Medium and Large(120-190mm)
- Material：Bearing Steel
- Spherical：Non-Aligning Bearings
- Load Direction：Radial Bearing
Base Info
- Model NO.：71822CD,P4
- Separated：Unseparated
- Product Name：High Super Precision 71822CD,P4 Angular Conta
- Size：110*140*16 mm
- Weight：0.51kg
- Basic Dynamic Load Rating：31.9kn
- Basic Static Load Rating：40.5kn
- Fatigue Load Limit：1.53kn
- Reference Speed：8000r,Min
- Limiting Speed：13000r,Min
- Calculation Factor：1.34
- Vibration：Zv1, Zv2, Zv3, or as Requested
- Transport Package：Single Box Packaging,OEM
- Specification：110*140*16 mm
- Trademark：TFN,OEM,SEMRI
- Origin：China
- HS Code：8482103000
- Production Capacity：10000,Month
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc. Cr/KN Cor/KN Grease Oil 73 serie 7303C 36303J 17 47 14 0.12 15.8 8.4 25000 33,000 angular contact ball bearing 7303BTN1 66303A 17 47 14 0.12 14.9 7.9 18000 23,000 angular contact ball bearing 7304C 36304J 20 52 15 0.146 18.5 9.95 23000 31,000 angular contact ball bearing 7304ACM 46304H 20 52 15 0.146 17.4 9.4 17000 21,000 angular contact ball bearing 7304BTN1 66304H 20 52 15 0.15 16.2 8.7 13000 17,000 angular contact ball bearing 7305C 36305J 25 62 17 0.23 26.4 15.3 19000 25,000 angular contact ball bearing 7305ACM 46305H 25 62 17 0.23 24.8 14.4 14000 17,000 angular contact ball bearing 7305BM 66305H 25 62 17 0.24 22.9 13.3 10000 14,000 angular contact ball bearing 7306C 36306J 30 72 19 0.35 32.3 20.3 16000 21,000 angular contact ball bearing 7306ACM 46306J 30 72 19 0.35 31 19.5 8000 11,000 angular contact ball bearing 7306BM 66306H 30 72 19 0.35 33.6 18 8000 11,000 angular contact ball bearing 7307C 36037J 35 80 21 0.47 37.9 23.6 14000 19,000 angular contact ball bearing 7307ACM 46037H 35 80 21 0.47 39 25 7800 1,050 angular contact ball bearing 7307BTN1 66037A 35 80 21 0.47 32.5 20.2 7700 10,000 angular contact ball bearing 7308C 36308J 40 90 23 0.69 46.3 29.4 13000 17,000 angular contact ball bearing 7308ACM1 46308H 40 90 23 0.69 49 33 7100 9,000 angular contact ball bearing 7308BTN1 66308A 40 90 23 0.69 39.7 25.2 6900 9,200 angular contact ball bearing 7309C 36309J 45 100 25 0.89 59.2 39.7 11000 15,000 angular contact ball bearing 7309ACM 46309H 45 100 25 0.89 65 45 6000 8,000 angular contact ball bearing 7309BTN1 66309J 45 100 25 0.89 50.6 34.1 6200 8,200 angular contact ball bearing 7310C 36310J 50 110 27 1.08 75.1 51.6 10000 13,000 angular contact ball bearing 7310ACM 46310H 50 110 27 1.08 71.5 49 5600 7,500 angular contact ball bearing 7310BTN1 66310A 50 110 27 1.08 64.4 44.3 5500 7,300 angular contact ball bearing 7311C 36311J 55 120 29 1.39 86.8 60.6 9300 12,000 angular contact ball bearing 7311ACM 46311J 55 120 29 1.39 88.4 63 5000 6,700 angular contact ball bearing 7311ACQ1/SO 46311QT 55 120 29 1.39 86 61.5 5000 6,700 angular contact ball bearing 7312C 36312J 60 130 31 1.71 99.2 70.3 8600 11,000 angular contact ball bearing 7312ACM 46312H 60 130 31 1.71 105 67 4500 6,000 angular contact ball bearing 7312BTN1 66312A 60 130 31 1.71 84.9 60.3 4600 6,200 angular contact ball bearing 7313C 36313J 65 140 33 2.09 112 80.7 8000 11,000 angular contact ball bearing
FAQ
FAQ 1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OEM
