HSS End Mills with Morse Taper Shank
Xuzhou Shangli Artware Co., Ltd.- Coating：Uncoated
- Tooth Form：Spiral Tooth
- Tooth Space：Sparse Tooth
- Structure：Integral
- Material：High-Speed Steel
- Type：Vertical Milling Cutter
Base Info
- Model NO.：metric and inch
- Size：12mm to 100mm
- Standards：DIN, ANSI, GOST, ISO
- Style：Universal Tool
- Cutting Process：Milling Cutter
- Work Type：Cut off
- Transport Package：Plastic Box
- Specification：10mm to 100mm
- Trademark：stc
- Origin：Zhenjiang Jiangsu
- HS Code：82077090
- Production Capacity：10000PCS,Month
Description
STC061, HSS TAPER SHANK END MILLDIN845, GOST17026
REGULAR LENGTH NON-CENTER CUTTING
Size Morse Taper Flute Length Overall Length
Size Morse Taper Flute Length Overall Length
Size Morse Taper Flute Length Overall Length
10 1 22 92
22 2 38 123
45 4 63 188 12 1 26 96
25 3 45 147
50 5 75 233 14 2 26 111
28 3 45 147
56 5 75 233 16 2 32 117
32 4 53 178
63 5 90 248 18 2 32 117
36 4 53 178
20 2 38 123
40 4 63 188
LONG LENGTH NON-CENTER CUTTING
Size Morse Taper Flute Length Overall Length
Size Morse Taper Flute Length Overall Length
Size Morse Taper Flute Length Overall Length
10 1 45 115
22 2 75 160
45 4 125 250 12 1 53 123
25 3 90 192
50 5 150 308 14 2 53 138
28 3 90 192
56 5 150 308 16 2 63 148
32 4 106 231
63 5 180 338 18 2 63 148
36 4 106 231
20 2 75 160
40 4 125 250
