Captain Gantry 2 Post Car Lift with High Quality
Shenzhen E-Fuel Technology Ltd- Type：Double Cylinder Hydraulic Lift
- Lifting Capacity：4T
- Driving Type：Hydraulic
- Certification：CE, ISO
- Driving Motor Number of Mechanical Lift：1
- Double Cylinder Lift Type：Thin Plate Type
Base Info
- Model NO.：2-post Clear Floor Car Lift
- Shearing Lift Type：Ultrathin Type
- Condition：New
- Brand：Captain
- Design：Two Post
- Lifting Height：1750mm
- Lifting Weight：4000kg
- Outline Dimensions：3370X500X3620mm
- up Lifting Time：55-65s
- Motor Power：2.2kw
- Power Supply：220V,380V, 1pH,3pH
- Rotation Angle：180
- Net Weight：650kg
- Transport Package：Export Container ,Pallet ,Disassembly with Carton
- Specification：CE, SGS, ISO
- Trademark：Captain,OEM
- Origin：Jiangsu, China.
- Production Capacity：196sets,Month
Description
| Features:1.Clear floor design, saving space.2.Antioxidant, environment-friendly electrostatic powder spray coating;3.Adopt double cylinder, 4x4 higher and stronger chain, the wire rope balance system.4.Three kinds of release for choice, manual two sides release, manual single side release, electrical release. 5.Rubber pad for protecting door from scratch.6.Safety guard to protect toes.7.Rubber support with 3 phases to adjust height. 8.Limit switch to avoid hitting the top of the car. 9.The arms adopt 2 stages or 3 stages design, larger range adjustment, suitable for different vehicle chassis. |
| For 2-post car lift, we have 2 kinds of arms, symmetrical arm and unsymmetrical arms. |
