Stage Performance LED Rental Video Screen
Luoyang Tianpeng Packaging Product Co., Ltd.- Tube Chip Color:Full Color
- Display Function:Video, Image, Animation, Graphics, Text etc.
- Pixel Pitch:3mm
- Pixel Configuration:1r1g1b(3in1)
- Pixel Density:111111 Dots,Sq.M
- Scanning Mode:Constant Current
Base Info
- Model NO.:SY-P3-16S
- System Operating Platform:Win98,Win2000,Win XP,Win 7,Win 8
- Display Type:LED Video Display
- Application:Stage Performance, Advertising, Shopping Guide
- IP Rating:IP40
- Certification:CE, RoHS, FCC
- Warranty:Two Years Warranty After Shipping
- Power Supply:G-Energy, Meanwell, Rongdian etc.
- Transport Package:Wooden Box or Fly Case
- Specification:CE, RoHS, FCC
- Trademark:SENY
- Origin:Shenzhen, Guangdong, China
- HS Code:8528591090
- Production Capacity:5000 Sqm,Month
Description
Stage Performance LED Rental Video ScreenS/NItemTechnical ParametersLED Parameters1Item NameLED Chip BrandBrightnessWave LengthH/V Visual Angle2Red LEDEpistar120-140mcd620-625nm140º/65º3Green LEDEpistar360-435mcd520-525nm140º/65º4Blue LEDEpistar80-100mcd470-475nm140º/65ºModule Specification1Pixel Pitch3mm2Pixel Configurationsmd2121(1R1G1B)3Module Resolution64 x 64 pixels4Module Pixles4096 pixels5Module Size192mm X 192mmCabinet Specification1Cabinet Size(W X H X D)576mm x 576mm x 80mm2Cabinet Resolution(dot)192 x 192 pixels3Module Quanity (pcs)9pcs4Cabinet Pixels36864 pixels5Pixel Density111111 pixels/m26Cabinet MaterialsDie Casting Aluminum Cabinet for rental purpose7Cabinet Weight9.2kg per cabinet8PackagingFly case9Fly Case Size77CM*63CM*80CM ( one case for six cabinets )Whole Screen Specification1Screen Brightness≥1200cd/m22Driving Method1/32 scan3Best Viewing Distance3m - 30m4Max. Power Consumption1000W/m25Average Power Consumption500W/m26Gray Level8bits input, 4096 levels(212)7Display Color16M8Frame Frequency≥60Hz9Refresh Frequency≥1200Hz10Uninterrupted Working Hours≥72 hours11Screen Life-span≥100,000 hours12MTBF≥5,000 hours13Discrete Blind Spot Rate<1/1000014Continuous Blind Spot RateNone15Blind Spot Rate<1/1000016Protective ScaleFor indoor use only17Screen Plainness<±1mm18Power Supply ModeAC220±10% 50Hz/AC110±10% 60Hz19Environment Temperature & HumidityTemperature:-20 Celsius~+60 CelsiusHumidity:10%~90% RH20Control ModeSynchronous display with control PC by DVI21Control SystemLinsn, Nova-star, Colorlight or as you required22Display ContentVideo, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.23InterfaceStandard Ethernet24Transmission DistanceMulti mode fiber <500m, single mode fiber <30km,internet cable <100m25CertificateCE, RoHS, FCCProject cases:

After sales maintenance:
1.Receive the cargo
Make sure the cargo in sealing condition and the cargo storage temperature between - 20ºC and 60ºC when you receive the goods.
2. Install and use the product
Please adopt preheating model to light it up and keep 30% brightness for 0.5-2 hours when using . Keep it work 8 hours or above continually per day will be better. It will be better to use it at least once a week.
3. Cleaning
Ensure to use soft brush to clean the display surface and PROHIBIT any liquid
when doing cleaning.
