• Model NO.：GLT2000-5M
• Delivery Time：15-25days
• Colour：Orange, White, Yellow, Red, Blue, etc.
• Transport Package：Shrik Wrap or Wooden Box
• Specification：ISO9001 approved
• Trademark：Genlitec Power
• Origin：Fuzhou, China
• HS Code：9405409000
• Production Capacity：300 Units Per Month

Basic Info.

Model NO. GLT2000-5M Delivery Time 15-25days Colour Orange, White, Yellow, Red, Blue, etc. Transport Package Shrik Wrap or Wooden Box Specification ISO9001 approved Trademark Genlitec Power Origin Fuzhou, China HS Code 9405409000 Production Capacity 300 Units Per Month

Product Description

Δ STANDARD CONFIGURATION
1) Powerful 4*500W metal halide lamps (Flood lights or spotlights)
2) Powered by GENLITEC air-cooled single cylinder diesel engine DE186FAE
3) Durable fixtures resist shock and last longer
4) Unique lamp design increases filament life and keeps maximum light on the job longer
Increasing productivity while saving time and money
5) Four leveling jacks provide stability
6) Durable 5m mechanical mast with 1200lbs self-lock winch
9) ±90° non-continuous  lamp set rotation system

Δ TESTING ITEMS
GENLITEC POWER provides a full line of brand new and high quality products.
Each and every unit is strictly factory tested before shipment.
1) Parts faults testing
2) Fuel tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insulation testing
6) Noise testing
7) Loading Testing: 25%, 50%, 75%, 100%, 110% load to check verify that all control systems, alarm and shut-down protection.






Δ TECHNICAL DATA

MODEL	GLT2000-5M
Type of Lights	Metal Halide Lamps
No. & Power of Lights	4x500W
Lights Bar Tilting System	90° Manual Operation
Light Capacity	4x40000Lumen
Mast Lifting System	Vertical Mechanical
Mast Section	3
Max. Height of Mast	5 meters
Brake System	Mechanical Parking Brake
Engine Model	DE186FAE
Engine Speed	3000/3600RPM
Max. Power	9.0HP
Displacement	416CC
No. of Cylinder	Single
Engine Type	Air-cooled, 4 stroke DIESEL
Frequency	50/60Hz
Phase	Single
Generator Rated Power	4.5/5.0KW
Fuel Tank Capacity	16L
Continuous Operation Time	15 hours
Dimension (LxWxH)	1200*600*2200mm
Net Weight	280kg
